1OM-1610
2. Name and Function of Each Section : Chap.1
1-90911-001
Short Appendix : Cover Lock Switch
Switch ON
LED ON
Switch ON
LED OFF
Cover Lock Switches
Switch Status Machine Status
LED ON
"Operation of Cover Lock" Permitted by Operator
Electromagnetic Locks of
Transparent Covers :
Locked
(Transparent Covers Opening
Impossible)
Switch Status Machine Status
LED OFF
"Operation of Cover Lock" Rejected by Operator
Electromagnetic Locks of
Transparent Covers :
Unlocked
(Transparent Covers Opening /
Closing Possible)
1OM-1610
1-10
2. Name and Function of Each Section : Chap.1
0911-001
2.4 Cover Section
DANGER
There are strong motorized and high-voltage areas
inside the machine. Special caution should be paid
not to touch them.
Doing otherwise will cause personal injury (serious
accident).
•
Only qualified maintenance personnel should
detach the covers.
•
The machine should be operated with the covers
being attached.
•
If a cover is detached, be sure to reattach it.
•
Be sure to close the transparent covers (door
type) before operating the machine.
•
Do not disengage the interlock mechanism of the
transparent covers (door type).
The transparent covers and safety doors are mounted on the upper side of the
beam unit and around the base respectively, so that any part of your body, clothes
or object is not in contact with the moving section inside the machine, to prevent
any danger during the automatic operation.
Safty Cover (located around frame)
Machine Front Side
Storage Cover of
Electrical Part Storage Box
(located on the lower area
of both conveyor ends)
Cover Lock Switch
(Stage ready Switch)
Transparent Cover
(Door Type, Located over the beams)
Transparent Cover
(Door Type, Located over the beams)
Safty Cover
(located around frame)
F1A6
1OM-1610
2. Name and Function of Each Section : Chap.1
1-110911-001
The transparent covers on the upper area of the beams are provided with [Cover
Lock] switches. When the switch is pressed after the transparent cover (door type)
is closed, the LED turns on, indicating that the transparent cover cannot be opened
(locked electromagnetically).
WARNING
Be sure to keep the all
transparent covers closed to
avoid any danger when the automatic operation is
started or during the automatic operation.
CAUTION
Avoidhandandngerinjuries.
•
Be careful to avoid hand and nger injuries when
closing the transparent covers.
•
Hold the handgrip rmly and open or close the cover
slowly.
