1OM-1610
5-10
1. Specications : Chap.5
0911-001
Item Description
14. Number of
Stocked Nozzles
High-Speed Head Multi-Functional Head
Nozzle Stocker for High-Speed
Components
Max. 15 nozzles can be stored for
each head.
Nozzle Stocker for Middle-Size
and Odd-Shape Components
Max. 8 nozzles can be stored for each
head.
Notes :
(a) Increase of the quantity
of nozzle to be stocked
is available by means
of adding the nozzle
stockers (option).
(b) When the vacuum
nozzles for the
middlesize and odd-
shape components are
used, the nozzle stockers
for the middle-size and
oddshape components
are required.
Nozzle Stocker for Multi-
Functional Head
Max. 9 nozzles can be stored for each
head.
Notes :
(a) Use the nozzle stocker
for multi-functional
head.
(b) Increase of the quantity
of nozzle to be stocked
is available by means
of adding the nozzle
stockers (option).
15. Number of
Installable
Feeders
(1) Tape Feeders
Max. 30 feeders
(when only 8 mm dual tape feeders are used)
Ref.
: Up to 120 types of components can be loaded.
Max. 30 feeders
(When only 12 / 16 mm tape feeders are used)
Max. 15 feeders
(When only 24 / 32 mm tape feeders are used)
Max. 10 feeders
(When only 44 / 56 mm tape feeders are used)
Max. 7 feeders
(When only 72 mm tape feeders are used)
(2) Vibratory Stick Feeders
Max. 5 per feeder base
Ref. :
Up to 6 carrier sticks can be installed on one vibratory stick feeder.
Notes :
(a)
The number of installable feeders varies according to the
combination of the reel width for the taping and the feeders.
(b) Use the tape feeder for the SIGMA- G4/G5. In the case that the
tape
feeder for the GXH-1 / GXH-3 series is used, the operational
conditions are partly restricted.
(c) The
dual tape feeder, bulk feeder and tapes for the other machines
(ie. machines excluding SIGMA-G4/G5, GXH-series) cannot be
used.
T1E1-10
1OM-1610
5-11
1. Specications : Chap.5
0911-001
Item Description
16. Memory Capacity
of Pattern
Program Data
Maximum Number of Steps : 20,000 steps/model (For repetitive patterns)
Maximum Memorized Number of Models : 24 models
Note :
The above numbers are limited according to the capacity of the
pattern program data per model.
17. Input System and
Output System of
Pattern Program
Data
•
Operated using the touch screen on the main machine and edited using the
keyboard/pointing device (Option).
•
Pattern program data can be edited with the network terminal (Option).
•
Data can be entered through the local area network (Ethernet) running from
the data storage device of the network terminal (Option).
•
Data
Transfer to Storage of Network Terminal (Option).
18. Component
Recognition
V
isual Field
φ
62 mm
The dimension in Y direction must be 46.7 mm.
Y (direction)
F 62
Unit : mm
Photoimage Front Lighting System
(Direct Recognition of Component by Front Lighting)
Note :
Some limitation is imposed, depending on the types of
components.
Back Lighting System
(Recognition by Component Silhouette)
Note :
Some limitation is imposed, depending on the types of
components.
In the back lighting system, specied nozzle are
required for the middle-size odd-shaped components
and the multifunctional nozzle on the multifunctional
head.
For the Back Lighting System, the static image is shot
using the camera.
T1E1-11
1OM-1610
5-12
1. Specications : Chap.5
0911-001
Item Description
19. PEC Recognition Visual Field Approx. 12
×
12 mm
Window
Size
Max. 10.0
×
10.0 mm
Recognition
(Process)
Time
Approx. 0.06 seconds / mark
(including the time to capture an image)
Photoimage Front Lighting System
(Recognition of Fiducial Mark by Front Lighting)
("Normal" or "Reverse" can be selected for each mark.)
20. Fiducial Marks Refer to "Fiducial Marks" for details.
21. Air Supply Supply
Pressure
0.45 to 0.69 MPa (4.6 to 7 kgf/cm
2
)
Set Pressure 0.45 MPa (4.6 kgf/cm
2
)
Note :
Min. 0.4 MPa (4.1 kgf/cm2) of air is necessary for
operation.
•
Use the dry and clean air as follows
Moisture : Dew Point
−
17
°
C or lower (Atmospheric Pressure)
Oil
: 0.1 mg/m
3
or less (ANR)
Dust : Solid Material 0.01
µ
m or less
22. Air Consumption Approx.
30 L/min (during automatic operation)
Approx. 110 L/min (when one feeder base moves up and down)
23. Vacuum Pressure
−
93 kPa (70 cmHg)
T1E1-12
