5. Various Functions : Chap.1
0911-001
5.3 Functions related to Component Replenishment
5.3.1 Alternate Feeder Function (Mode)
When a feeder becomes short of components, this function selects a prepared
spare feeder. After all components are picked up from the spare feeder, another
spare feeder is selected. The prepared spare feeders must contain the components
of frequently used types.
The feeders can be replenished collectively with components, prolonging the
interval time for component replenishment.
5.3.2 Automatic Recovery Function
When this function is used and a component shortage error is detected, the
machine is not stopped and a message is issued as machine information,
prompting the operator to replenish components.
The machine continues to place the components other than the missing ones
(component-shortage detected ones). After it has placed all components (excluding
the missing ones), it stops running without discharging the PCB.
When component shortage errors, etc., are detected in different feeders at a short
interval, the loss time can be reduced because the components in short can be
replenished collectively.
5.3.3 Component Remainder Management Function
This function controls the number of remaining components and issues a warning
message, indicating that the machine will soon become short of components.
When the waring message is received, the component replenishment can be
prepared beforehand, reducing some loss time.
5.3.4 Splicing Function
This function makes it possible to splice the end of the component tape of the tape
feeder and a new component tape for component replenishment.
Thus, the time of the automatic operation stop can be reduced.
A splicing tape and a tape cutting jig (option) are required for the tape splicing.
1OM-1610
0911-001 2-A
Chapter 2
Operation Windows
In this chapter, the basic items necessary to operate the machine, such
as the system start-up and shut-down procedures, operation window
configuration, operation environments and main menu bar, etc., are
described.
It is recommended that the person who operates this machine has learned the basic
operation procedures of the Windows. There are many guidebooks to Windows. It
is recommended that operators familiarize themselves with the proper procedures.
1. Starting
2. Operation Screen
3. Entry of Each Paramenter
4. Exiting from the System Program
