1OM-1610
4-16
3. Program Change Operation : Chap.4
3.5 ConrmationofPCBTransferandPositioning
The following describes how to check the status of the PCB transfer and
positioning in the "PCB XFER" window (a menu of "AUTO OPN").
Procedure
(1) Display the "PCB XFER" window using the following icon procedure.
F1D17
(2) Input the PCB from the input machine.
Reference
When the PCB is to be input manually, refer to "3.1.1 PCB Manual Input
Procedure", in Chapter 3.
(3) Select a desired block button (expressed graphically) for "PCB LOCATE L".
In 10 seconds, press the [START] button on the operation panel to transfer
the PCB.
(4) Conrm that the PCB can be transferred normally and move smoothly
without falling down during the transfer.
(5) Press the [Execute] button (entitled "PCB LOCATE L").
In 10 seconds, press the [START] button on the operation panel.
The backup base moves up.
(6) Press the cover lock switch to turn off the lamp.
The transparent cover (door type) is unlocked.
Graphic
Development
0911-001
1OM-1610
4-17
3. Program Change Operation : Chap.4
(7) Open the transparent cover (door type).
CAUTION
The load power to the motors, etc., is turned OFF
but the setup operation must be performed carefully
when you put your hand inside the machine. Avoid
handandngerinjuries.
(8) Slightly push the PCB by nger to conrm that there is no problem in the
location of the support pins.
(9) Close the transparent cover (door type).
(10) Press the cover lock switch to turn on the lamp.
0911-001
1OM-1610
4-18
3. Program Change Operation : Chap.4
3.6 ConrmationofComponentPickupPosition
In normal cases, it is not necessary to check the pickup position because slightly
shifted position is automatically adjusted.
However, when a component that requires to be positioned precisely cannot be
picked up correctly for the rst time, a teaching operation must be performed on
the feeder Pickup Position.
