1OM-1610
5-18
1. Specications : Chap.5
Item Description
39. Others Standard Functions
•
Component Library Teaching Function (GS-TR100)
•
Placement Position
Teaching Function (GS-TZ100)
•
Application for BGA/CSP
(GS-TB100)
•
Automatic Recovery Function for Component Pickup Errors
•
Component Pick-Up Position
Teaching Function
•
Delayed Recovery Function (Recovery Mode)
•
Alternate Component Supply Function
•
Pick-Up and Placement Up/Down-Axis (L-Axis) Control Function
•
Pick-UP
Position (X/Y) Correction Control Function
•
Pocket outline recognition
•
T
wo-stage placement Z-Axis speed reduction
•
Nozzle existence check before pick-up
Dual Function
•
Pattern Program for Dual T
ransfer Mode
The pattern program data preparation, optimization or multi-production
model line balance is performed using the dual transfer system software.
T1E1-18
0911-001
1OM-1610
5-19
1. Specications : Chap.5
1.2 Standard Accessory Parts List
No. Product Name Part No. Q'ty Remarks
1 Lens Cleaning Cloth
15 cm
×
15 cm
226J1560 5
2 Glass Tube Fuse (6.3 A) 4S300023 1
•
Spare
3 Glass Tube Fuse (5 A) 4S300024 1
•
Spare
4 Glass Tube Fuse (3.15 A) 4V320011 1
•
Spare
5 Glass Tube Fuse (10 A) 4V320010 1
•
Spare
6 Fuse with an Alarm Contact (5A) 4S300006 1
•
Spare
7 Flat-Type Fuse (5 A) 4S300010 1
•
Spare
8 Fuse (2 A) 0916D207 1
•
Spare
9 Splicing Joint Detector Cleaning
Long Stick with a Rope
0926B109 1
•
For Cleaning the Splicing Joint
Detector
10 Splicing Joint Detector Cleaning
Cotton Applicator
0926B10A 1
•
For Cleaning the Splicing Joint
Detector
11 Flame Leg Receiver 216R0353 4
12 Collar (BS Spacer) 216A0334 4
•
Flame Leg Receiver
13 Set Screw 221CA010 4
•
Flame Leg Receiver
14 Padlock 226J0574 2
•
For Locking Power Breaker and
Air Source
15 QFP Glass Plate Jig
(JG-0188)
211D9639 1
•
For Of
fset Teaching
16 Nozzle (HA09) 09429104
1
17 Nozzle (PK01) 0974J00Q 1
•
For Support Pin Pick-up
18 Filter 225A0045 960
19 Flat Ring 226A0256 3
•
For Roller on Oscillating Side in
Cutter Section
20 Tape Cutting Jig 09141J03 1
21 PCB Support Pin 0974900M 40
•
For PCB Support Pin
T1E2-1
0911-001
1OM-1610
5-20
1. Specications : Chap.5
1.2.1 Head Accessory List
• High Speed Head
No. Product Name Part No. Q'ty Remarks
1 Vacuum Filter 225B0572 90
2 High-Speed Nozzle Stocker
Replacement Section
09198000 1
T1E2-2
• Multi-Functional Head
No. Product Name Part No. Q'ty Remarks
1 Multi-Functional Head Filter 225B0313 18
T1E2-3
NOTE :
These head accessories are attached for each head.
0911-001
