2-81
2
Operation
2. Check the packagings which are not enough. Items are listed in "Missing item list".
Select job orders and select "Print missing items" in Menu, then the job orders are listed in "PRINT PREVIE" screen.
Press [Save] button to save the list in pdf format, press [Export] button to save the list in XML format.
If the machine is connected to a printer through an external network, pressing [Print] button prints the list.
"PRINT PREVIEW" screen "Missing item list"
[Export] button [Save] button
[Print] button
24299-KMS-00
n
NOTE
Print analysis list
Select job orders and select "Print analysis list" in Menu, then the selected job orders and necessary items are listed in
"PRINT PREVIE" screen.
Press [Save] button to save the list in pdf format, press [Export] button to save the list in XML format, same as the other
list.
If the machine is connected to a printer through an external network, pressing [Print] button prints the list.
"PRINT PREVIEW" screen
[Export] button [Save] button
[Print] button
242A0-KMS-00
2-82
2
Operation
3. Setting of alias for the items
Select the job orders, and press [Details] button, then the items associated with the job orders are listed.
Select the item which is not enough ( are attached on right of the), and press [Alias] button.
The screen of alias settings appears. Select the necessary items if they can be alias of the items.
"PLANNER" screen [Detail] button
[Detail] button
Tick the job orders
242A1-KMS-00
Alias setting
Select the item
[Alias] button
242A2-KMS-00
2-83
2
Operation
6
Move the job order into JOB ORDERS screen.
Move the job orders with , which are OK about production analysis, into "JOB ORDERS" screen.
Select the job orders and press [Processing] button, then move the job orders into "JOB ORDERS" screen.
See "3.6.4 Unload packagings by a job order" to unload the necessary packagings.
Move job orders from "PLANNER" to "JOB ORDERS"
[Processing] button
Tick the check box
242A3-KMS-00
