2-50
2
Operation
n
Functions of buttons
Icon Button name Description
Add button
Items which are not in "Items" table can be newly registered by this button.
See "3.2.2 Register an item manually" for the process for registering items.
Zoom button Able to zoom in "Items" table.
Arrow button Able to register the selected item into "Bill of materials" table.
OEM button
OEM: Original Equipment Manufacturer
Able to make a limit of manufacturer of items. See below for the details.
Remove button Remove the items registered in "Bill of materials" table.
• [OEM] button
Select the item in "Bill of materials" and press [OEM] button, then "OEM-APPROVALS" screen appears.
The manufacturer of the selected item can be specified in this screen.
Select a specified manufacturer and press [Select] button, then the manufacturer is specified as OEM item for Job orders.
"OEM - APPROVAL" screen
[Select] button [OEM] buttonSelect Manufacturer
24255-KMS-00
2-51
2
Operation
n
"Duplicate" function to register a BOM
Select a BOM in "BOM" screen and select "Duplicate" in Menu, then "DUPLICATE" screen appears
A new BOM is registered by duplicating the selected BOM in this screen.
[Menu] button - "Duplicate"
[Menu] button
“Duplicate”
24256-KMS-00
"DUPLICATE" screen
24257-KMS-00
TIP
BOMs which are registered by "Duplicate" function have thier BOM codes with "Copy" indication.
2-52
2
Operation
3.5.3 Register a BOM by import function.
Registering a BOM by import function.
n
NOTE
The import function for BOM can't register multiple BOMs at once but can register only a BOM one by one.
1
Open "IMPORT" screen.
Select "Import" in Menu, then "IMPORT" screen appears.
Import menu
“Import”
[Menu] button
24258-KMS-00
2
Select the file format in "IMPORT" screen.
"IMPORT" screen
24259-KMS-00
Content Description
XML Mode Normally import files are txt or csv format. If the import file is xml format, tick this.
Separator Select the separator from " ; ", " : ", " , ", or " . ".
