2-1 2 Daily maintenance items 1. Main unit 1.1 Checking tower signal & operator area indicator Check if the to wer signals and operator area indicators work properly ev eryday . If there is difference between the mac…
2-1
2
Daily maintenance items
1. Main unit
1.1 Checking tower signal & operator area indicator
Check if the tower signals and operator area indicators work properly everyday.
If there is difference between the machine operation and these lighting, there might be something wrong with
the machine.
Tower signal & operator area indicator
Tower signal Operator area indicator
Operation
indicator
Power
indicator
Red
White
Green
Yellow
53201-KMS-00
Color Status
Signal tower lighting Red Emergency stop, Error occurs
Green In automatic operation
Yellow & Green In unloading components
White and Green In loading components
Yellow Components exist in loading/unloading area
Operator area indicator Operation indicator (green) All control boards are able to operate
Power indicator (white) Operation switch of the machine is on
2-2
2
Daily maintenance items
1.2 Dehumidifier operation
Check if dehumidifiers work properly.
1
Press [Charts].
Press [Charts] in right of the screen to display "Environment Condition" screen.
Press [Charts]
[Charts] button
54201-KMS-00
2
Check "ENVIRONMENTAL CONDITIONS" screen.
The record of humidity monitored inside/outside the machine is displayed in right of "ENVIRONMENTAL
CONDITIONS" screen.
Select date on top of the screen and press [Chart], then the record of temperature and humidity during
the period appears.
Here the selected date is 11 to 18, July, 2018.
Check if the machine inside is dehumidified when the dehumidifiers work.
“ENVIRONMENTAL CONDITIONS” screen
[Chart] button
Humidity outside
Humidity inside
54202-KMS-00
n
NOTE
Dehumidifier monitoring works only while the operation switch is ON (Operation indicator lights green).
TIP
The performance of dehumidifiers depends on the environment such as the place where the machine is installed.
TIP
YST15 doesn't have the function to adjust temperature. The temperature record is just reference.
