2-24 2 Operation 3.2.4 Disable and remove items Set "Disable"on items so that the machine can't unload the items. 1 Select the item. Select the item to be disabled. 2 Select "Disable". Select &qu…
2-23
2
Operation
3
Press [Browse] button to select the import file.
Select the import file
Select the import file
[Open] button [Browse] button
24220-KMS-00
n
NOTE
Select the format from txt, csv or xml, depending on the import file format.
4
Press [Open] button to register items.
TIP
For example, six items are registered by the the following file.
e.g. Six items are registered by the the following file.
• Setting for "IMPORT" screen • The details of items • Import file in txt format
XML Mode
Separator
Code
Description
Item Type
MSL
Safety Stock
"Safety stock
(Production line warehouses)"
"Min. packaging count
(Production line warehouses)"
N/A
;
Column 1
Column 2
Column 3
No import
No import
No import
No import
Code
A01005
A0201
A0402
A0603
A0603NV
A01005
Description
RC1206JR-05600KL
TH capacitor 50nF
Ltt_234
BGA225 HGtfr
RC0805JR-0710K
RC1206JR-05600KL
Item type
1
2
1
1
1
1
23210-KMS-00
2-24
2
Operation
3.2.4 Disable and remove items
Set "Disable"on items so that the machine can't unload the items.
1
Select the item.
Select the item to be disabled.
2
Select "Disable".
Select "Disable" in Menu, then the selected item becomes disabled and hidden from the list.
Disable setting for items
Select the item
“Disable”
[Menu] button
24221-KMS-00
n
The case it is required to use the disabled item.
1
Show all items.
Select "Show All" in Menu, then all items including disabled items are displayed.
2
Select the item.
Select the required item.
3
Select "Enable".
Select "Enable" in Menu, then the selected item becomes enabled.
Enable setting for items
Select the item
“Enable”
[Menu] button
24222-KMS-00
2-25
2
Operation
TIP
[Remove] button, which is displayed only for engineer authority.
Select an item and press [Remove], then the item is removed.Items which are removed once are not able to be
registered again, and the histories of them are also removed in traceability.
DO NOT remove any registered items basically.
[Remove] button
[Remove] button
24223-KMS-00
Existing Code
24224-KMS-00
