2. Wiring and Connection
2 - 15
(2) Connecting the magnetic sensor
Refer to section (1) for connection with the spindle motor.
Name
P15(+15V)
MAG
LS
Pin
1
2
3
4
5
6
7
8
9
10
MDS-C1-SPA
Option cable : CNP6M
Option cable : CNP5
U VW
U V W
CN5
Spindle m otor
Magnetic sen s or
Power cable
Max. 30m
CN6
Spindle
Pin No.
Detector connector : CN6
No.1
No.10
No.11
No.20
Name
LG
MAGR
LSR
Pin
11
12
13
14
15
16
17
18
19
20
CAUTION
1. The shield of spindle detector cable is not FG. Do not ground.
2. The magnetic sensor orientation is not available with a machine having a
gear ratio between the motor and spindle exceeding 1:31.
2. Wiring and Connection
2 - 16
(3) Connecting the spindle side detector
Refer to section (1) for connection with the spindle motor.
U VW
U V W
CN5
Spindle motor
CN6
Option cable: CNP6A
Power cable
MDS-C1-SPA
Max. 30m
Option cable : CNP5
Spindle side detector
Spindle
Pin No.
Detector connector : CN6
No.1
No.10
No.11
No.20
Name
LG
MA*
MB*
MZ*
LG
P5(+5V)
P5(+5V)
Pin
11
12
13
14
15
16
17
18
19
20
Name
LG
MA
MB
MZ
P5(+5V)
Pin
1
2
3
4
5
6
7
8
9
10
CAUTION
The shield of spindle detector cable is not FG. Do not ground.
2. Wiring and Connection
2 - 17
2-5 Connection of power supply
CAUTION
1. Make sure that the power supply voltage is within the specified range of each
unit. Failure to observe this could lead to damage or faults.
2. For safety purposes, always install a No-fuse breaker (NFB), and make sure
that the circuit is cut off when an error occurs or during inspections.
3. The wire size will differ according to each drive unit capacity.
4. For safety purposes, always install a magnetic contactor (contactor) on the
main circuit power supply input. Large rush currents will flow when the power
is turned ON.
5. A semiconductor element is used in the power supply unit's magnetic contact
drive circuit, and a surge absorber is installed to protect the element.
Therefore, a leakage current of approx. 15mA is passed. Confirm that the
exciting coil in the magnetic contact will not function at 15mA or less.
2-5-1 Power supply input connection
(1) When using one power supply unit
Install the drive units so that the distance between power supply unit and spindle drive unit will be
3cm or less.
AC
reactor
Contacto
r
MC1
T
S
R
No-fuse
breaker
Ground
: Main circuit
: Control circ uit
CN4
L1
L2
L3
L11
TE3
TE1
L+
L-
MDS-C1-SPA
MDS-C1-CV
TE3
TE2
L+
L-
L11
L21
TE2
Ground
Ground
L21
MC
Breake
r
CN4
CAUTION
1. The power supply unit is a power supply regenerative type converter; an AC
reactor is surely installed in the power supply line.
2. When connecting to the TE3 terminal, connect to the power supply side
(primary side) of the AC reactor.
