3. Setup
3 - 7
No. Abbr. Parameter name Details
Setting range
(Unit)
Standard
setting
SP017 TSP Maximum motor speed
Set the maximum spindle motor speed. 1 to 32767
(r/min)
6000
SP018 ZSP Motor zero speed
Set the motor speed for which zero-speed signal output
is performed.
1 to 1000
(r/min)
50
SP019 CSN1 Speed cushion 1
Set the time constant for a speed command from "0" to
the maximum speed.
(This parameter is invalid when the S analog
synchronous tapping is valid.)
1 to 32767
(10 ms)
30
SP020 SDTS
Speed detection set
value
Set the motor speed for which speed detection output is
performed.
Usually, the setting value is 10% of SP017 (TSP).
0 to 32767
(r/min)
600
SP021 TLM1* Torque limit 1
Set the torque limit rate when the torque limit signal 1 is
assigned to the general-purpose input and the input is
turned ON.
0 to 120 (%) 10
SP022
VGNP1
Speed loop gain
proportional term under
speed control
Set the speed loop proportional gain in speed control
mode. When the gain is increased, response is
improved but vibration and sound become larger.
0 to 1000 63
SP023 VGNI1
Speed loop gain integral
term under speed
control
Set the speed loop integral gain in speed control mode.
Normally, this is set so that the ratio in respect to SP022
(VGNP1) is approximately constant.
0 to 1000 60
SP024 Not used. Set "0". 0 0
SP025 GRA1
Spindle gear teeth count
1
Set the number of gear teeth of the spindle
corresponding to gear 000.
1 to 32767 1
SP026 GRA2
Spindle gear teeth count
2
Set the number of gear teeth of the spindle
corresponding to gear 001.
1 to 32767 1
SP027 GRA3
Spindle gear teeth count
3
Set the number of gear teeth of the spindle
corresponding to gear 010.
1 to 32767 1
SP028 GRA4
Spindle gear teeth count
4
Set the number of gear teeth of the spindle
corresponding to gear 011.
1 to 32767 1
SP029 GRB1
Motor shaft gear teeth
count 1
Set the number of gear teeth of the motor shaft
corresponding to gear 000.
1 to 32767 1
SP030 GRB2
Motor shaft gear teeth
count 2
Set the number of gear teeth of the motor shaft
corresponding to gear 001.
1 to 32767 1
SP031 GRB3
Motor shaft gear teeth
count 3
Set the number of gear teeth of the motor shaft
corresponding to gear 010.
1 to 32767 1
SP032 GRB4
Motor shaft gear teeth
count 4
Set the number of gear teeth of the motor shaft
corresponding to gear 011.
1 to 32767 1
Parameters having an abbreviation with "*" (TLM1*, etc.) are validated right after the settings are changed by the personal
computer, without turning the spindle drive unit's power ON and OFF.
3. Setup
3 - 8
No. Abbr. Parameter name Details
F E D C B A 9 8 7 6 5 4 3 2 1 0
poff hzs ront
pycal
pychg
pyst pyoff sftk dflt
1a2m
bit Meaning when set to 0 Meaning when set to 1 Standard
0 1a2m 1 drive unit 2 motor function: Invalid 1 drive unit 2 motor function: Valid 0
1 dflt Default motor: Main Default motor: Sub 0
2 sftk Without SF-TK card With SF-TK card 0
3 0
4 0
5 0
SP033 SFNC1 Spindle function 1
6 pyoff This is set by Mitsubishi. Set to "0" unless particularly designated.
7 0
8 0
9 pycal (Conventional specifications)
High-speed rate deceleration
method valid for minimum excitation
rate
0
A 0
B 0
C ront Normal ready ON High-speed ready ON 0
D 0
Ehzs
Gate OFF by high-cycle zero speed
invalid
Gate OFF by high-cycle zero speed
valid
0
F poff
Contactor hold at NC power OFF
invalid
Contactor hold at NC power OFF
valid
0
(Note ) Set 0 if there is no particular explanation for the bit.
F E D C B A 9 8 7 6 5 4 3 2 1 0
mkc2 mkch
invm mtsl
bit Meaning when set to 0 Meaning when set to 1 Standard
0 mtsl Special motor constant invalid Special motor constant setting valid 0
1invm
A general-purpose motor FV control
invalid
A general-purpose motor FV control
valid
0
2 mkch Coil switch function invalid Coil switch function valid 0
3 mkc2 This is set by Mitsubishi. Set to "0" unless particularly designated. 0
4 0
5 0
SP034 SFNC2 Spindle function 2
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note ) Set 0 if there is no particular explanation for the bit.
3. Setup
3 - 9
No. Abbr. Parameter name Details
FEDCBA98765 4 3 2 10
lbsd hbsdlwidhwid
bit Meaning when set to 0 Meaning when set to 1 Standard
0hwid
H-coil wide-range constant output
invalid
H-coil wide-range constant output
valid
0
1lwid
L-coil wide-range constant output
invalid
L-coil wide-range constant output
valid
0
2 hbsd H-coil base slide invalid H-coil base slide valid 0
3 lbsd L-coil base slide invalid L-coil base slide valid 0
SP035 SFNC3 Spindle function 3
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
FEDCBA98765 4 3 2 10
dslm
dssm
enc2 enc1
mag2 mag1
plg2 plg1
bit Meaning when set to 0 Meaning when set to 1 Standard
0 plg1 PLG of motor 1 valid PLG of motor 1 invalid 0
1 plg2 PLG of motor 2 valid PLG of motor 2 invalid 0
2 mag1 MAG of motor 1 valid MAG of motor 1 invalid 0
3 mag2 MAG of motor 2 valid MAG of motor 2 invalid 0
4 enc1 ENC of motor 1 valid ENC of motor 1 invalid 0
SP036 SFNC4 Spindle function 4
5 enc2 ENC of motor 2 valid ENC of motor 2 invalid 0
6 0
7 0
8 dssm Speedometer output valid Speedometer output invalid 0
9 dslm Load meter output valid Load meter output invalid 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
