3. Setup
3 - 9
No. Abbr. Parameter name Details
FEDCBA98765 4 3 2 10
lbsd hbsdlwidhwid
bit Meaning when set to 0 Meaning when set to 1 Standard
0hwid
H-coil wide-range constant output
invalid
H-coil wide-range constant output
valid
0
1lwid
L-coil wide-range constant output
invalid
L-coil wide-range constant output
valid
0
2 hbsd H-coil base slide invalid H-coil base slide valid 0
3 lbsd L-coil base slide invalid L-coil base slide valid 0
SP035 SFNC3 Spindle function 3
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
FEDCBA98765 4 3 2 10
dslm
dssm
enc2 enc1
mag2 mag1
plg2 plg1
bit Meaning when set to 0 Meaning when set to 1 Standard
0 plg1 PLG of motor 1 valid PLG of motor 1 invalid 0
1 plg2 PLG of motor 2 valid PLG of motor 2 invalid 0
2 mag1 MAG of motor 1 valid MAG of motor 1 invalid 0
3 mag2 MAG of motor 2 valid MAG of motor 2 invalid 0
4 enc1 ENC of motor 1 valid ENC of motor 1 invalid 0
SP036 SFNC4 Spindle function 4
5 enc2 ENC of motor 2 valid ENC of motor 2 invalid 0
6 0
7 0
8 dssm Speedometer output valid Speedometer output invalid 0
9 dslm Load meter output valid Load meter output invalid 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
3. Setup
3 - 10
No. Abbr. Parameter name Details
FEDCBA98765 4 3 2 10
dplg ospcl
noplg
nsno nosg psdir plgo
mago
enco
bit Meaning when set to 0 Meaning when set to 1 Standard
0 enco Encoder orientation invalid Encoder orientation valid 0
1 mago Magnetic sensor orientation invalid Magnetic sensor orientation valid 0
2 plgo PLG orientation invalid PLG orientation valid 0
3 0
4 0
5 0
SP037 SFNC5 Spindle function 5
6 0
7 psdir Position shift standard Position shift reverse direction 0
8 nosg
No-signal detection type
(Always monitoring)
No-signal detection valid only in
position loop or orientation-mode
0
9 nsno No-signal detection valid No-signal detection invalid 0
A noplg
Constant monitor of PLG-Z phase
no-signal invalid
Constant monitor of PLG-Z phase
no-signal valid
0
B 0
C 0
D ospcl
Orientation speed clamp
motor speed setting
Orientation speed clamp
spindle speed setting
0
E dplg This is set by Mitsubishi. Set to "0" unless particularly designated. 0
F 0
(Note 1) For bit0 to 2, do not set two bits or more to "1" at the same time.
(Note 2) Set 0 if there is no particular explanation for the bit.
FEDCBA98765 4 3 2 10
oplp lmx iqsv
dcsn lmnp vfbs orm Tdn plg2 alty
bit Meaning when set to 0 Meaning when set to 1 Standard
0alty
Deceleration stop during special
alarm invalid
Deceleration stop during special
alarm valid
0
1 0
2 0
3plg2
Semi-closed pulse signal output×2
invalid
Semi-closed pulse signal output×2
valid
0
4 Tdn This is used by Mitsubishi. Set to "0" unless particularly designated. 0
SP038 SFNC6 Spindle function 6
5 0
6 orm Orientation start memo invalid Orientation start memo valid 0
7 vfbs This is set by Mitsubishi. Set to "0" unless particularly designated.
8 0
9 0
A lmnp This is set by Mitsubishi. Set to "0" unless particularly designated.
Bdcsn
Dual cushion during acceleration/
deceleration valid
Dual cushion during acceleration/
deceleration invalid
0
C 0
DIqsv
Elmx
This is set by Mitsubishi. Set to "0" unless particularly designated
F oplp Open loop operation invalid Open loop operation valid 0
(Note) Set 0 if there is no particular explanation for the bit.
3. Setup
3 - 11
No. Abbr. Parameter name Details
Setting range
(Unit)
Standard
setting
Set the spindle drive unit's capacity type.
(HEX setting)
Setting Unit capacity
S
etting Unit capacity
0000 --- 0010 MDS-B-SPA-550
0001 MDS-B-SPA-075 0011 ---
0002 MDS-B-SPA -15 0012 ---
0003 MDS-B-SPA -22 0013 ---
0004 MDS-B-SPA -37 0014 ---
0005 MDS-C1-SPA-55 0015 ---
SP039 ATYP Drive unit type 0006 MDS-C1-SPA-75 0016 --- 0000 to FFFF 0000
0007 MDS-C1-SPA-110 0017 ---
0008 MDS-C1-SPA-150 0018 ---
0009 MDS-C1-SPA-185 0019 ---
000A MDS-C1-SPA-220 001A ---
000B MDS-C1-SPA-260 001B ---
000C MDS-C1-SPA-300 001C ---
000D MDS-B-SPA -370 001D ---
000E MDS-B-SPA -450 001E ---
000F MDS-B-SPA -04 001F ---
This parameter is valid when SP034 (SFNC2)/bit0 is set
to "0". (Old type of motor)
Set the appropriate motor number from the standard
motors listed below.
(HEX setting)
Setting Motor name
Maximum
speed
Corresponding
drive unit
0000 --- --- ---
0001 SJ-2.2A 10000 r/min MDS-B-SPA -22
0002 SJ-3.7A 10000 r/min MDS-B-SPA -37
0003 SJ-5.5A 8000 r/min MDS-C1-SPA-55
0004 SJ-7.5A 8000 r/min MDS-C1-SPA-75
0005 SJ-11A 6000 r/min MDS-C1-SPA-110
0006 SJ-15A 6000 r/min MDS-C1-SPA-150
0007 SJ-18.5A 6000 r/min MDS-C1-SPA-185
0008 SJ-22A 4500 r/min MDS-C1-SPA-220
0009 SJ-26A 4500 r/min MDS-C1-SPA-260
SP040 MTYP Motor type 000A SJ-30A 4500 r/min MDS-C1-SPA-300 0000 to FFFF 0000
000B --- --- ---
000C --- --- ---
000D --- --- ---
000E --- --- ---
000F --- --- ---
0010 --- --- ---
0011 SJ-N0.75A 10000 r/min MDS-B-SPA-075
0012 SJ-N1.5A 10000 r/min MDS-B-SPA-15
0013 SJ-N2.2A 10000 r/min MDS-B-SPA-22
0014 SJ-N3.7A 10000 r/min MDS-B-SPA-37
0015 SJ-N5.5A 8000 r/min MDS-C1-SPA-55
0016 SJ-N7.5A 8000 r/min MDS-C1-SPA-75
0017 --- --- ---
0018 --- --- ---
0019 --- --- ---
001A --- --- ---
001B SJ-J2.2A 10000 r/min MDS-B-SPA-22
001C SJ-J3.7A 10000 r/min MDS-B-SPA-37
001D SJ-J5.5A 8000 r/min MDS-C1-SPA-55
001E SJ-J7.5A 8000 r/min MDS-C1-SPA-75
001F --- --- ---
