• ICCMAX is the maximum current processor can draw , typically seen running a virus application (stress applications specifically designed to push the SoC to maximum Power). With F ast Vmode enabled, output decoupling wo…
6. I
TRIPMax
is the peak current the VR FETs and inductors could see accounting for
the VR controller current measurement tolerance (TOL IMON ). The SoC VR and
system input power sources must be able to sustain this current for at least 10ms.
NOTE
TOL_IMON can be sometimes called as ITRIP_TOL or ITRIP_ACCURACY
7. V
TRIP
is the output voltage level below which the SoC will self-throttle. In
application, this voltage is internally set in the SoC and is not visible external to
the SoC. For the purposes of VRTT testing, a Vtrip will be provided for use with the
Python* test script used for FVM testing
Benefits
• The SoC droop detector and IMVP cycle by cycle limiting work together to allow
the voltage regulator inductors and FETs to be sized for realistic workload current
(~ICCMAX.APP) instead of virus currents (ICCMAX)
• Allows power sources to be sized for realistic workload currents, by shielding them
from SoC large dynamic loading events that occur when the SoC current exceeds
the worst case realistic maximum current (ICCMAX.APP).
Current Excursion Protection (CEP)
This power management is a Processor integrated detector that senses when the
Processor load current exceeds a preset threshold by monitoring for a Processor power
domain voltage droop at the Processor power domain IMVPVR sense point. The
Processor compares the IMVPVR output voltage with a preset threshold voltage (V
TRIP
)
and when the IMVPVR output voltage is equal to or less than V
TRIP
, the Processor
internally throttles itself to reduce the Processor load current and the power
DC Specifications
The processor DC specifications in this section are defined at the processor signal pins,
unless noted otherwise. For pin listing, refer to Package Ballout Mechanical
Specification:
•
for S/S Refresh/E/E Refresh -Processor line,download the pdf, click
on the
navigation pane and refer the spreadsheet, 743844-001_S_LGA_Ballout.xlsx.
•
for HX/HX Refresh-Processor line, download the pdf, click
on the navigation
pane and refer the spreadsheet, 743844-001_HX_Ballout.xlsm.
•
for H/H Refresh/P/U/U Refresh-Processor line, download the pdf, click
on the
navigation pane and refer the spreadsheet, 743844-001_HPU_Ballout.xlsm.
•
for PX-Processor line, download the pdf, click
on the navigation pane and refer
the spreadsheet, 743844-001_PX_Ballout.xlsm.
• The DC specifications for the DDR4/DDR5/LPDDR4x/LPDDR5/x signals are listed in
the Voltage and Current Specifications section.
• The Voltage and Current Specifications section lists the DC specifications for the
processor and are valid only while meeting specifications for junction temperature,
clock frequency, and input voltages. Read all notes associated with each
parameter.
13.1.5
13.2
R
Electrical Specifications—Intel
®
Core
™
, Xeon
™
6300 And Xeon
™
E 2400 Processors
13
th
Generation Intel
®
Core
™
, Intel
®
Core
™
14
th
Generation, Intel
®
Core
™
Processor (Series 1) and (Series 2), Intel
®
Xeon
™
E
2400 Processor and Intel
®
Xeon
™
6300 Processor
May 2025 Datasheet, Volume 1 of 2
Doc. No.: 743844, Rev.: 015 187
• ICCMAX is the maximum current processor can draw, typically seen running a
virus application (stress applications specifically designed to push the SoC to
maximum Power).
With Fast Vmode enabled, output decoupling would see this ICCMax current.
Output decoupling would need to be able to take transient load step up to this
ICCMax.
Power Stage (FET/Inductor) would only see ITRIP current
• ICCMax.app is less than IccMax and is the electrical current Drawn by the SoC
(per power rail) while running a typical user realistic application(s) scenario at
P0nmax and Tjmax.
It Corresponds to Pmax.App, The SoC VR and system input power. Source must be
able to sustain this current for at least 10 ms
• AC tolerances for all rails include voltage transients and voltage regulator voltage
ripple up to 1 MHz. Refer additional guidance for each rail.
Processor Power Rails DC Specifications
VCC
CORE
DC Specifications
Table 77. Processor VCC
CORE
Active and Idle Mode DC Voltage and Current
Specifications (S and S-Refresh Processor Line)
Symbol Parameter Segment Minimum Typical Maximum Unit Note
1
Operating
Voltage
Voltage
Range for
Processor
Operating
Mode
S/S Refresh
- Processor
Line
0 — 1.72 V
1,2,3,
7,12,15
IccMAX
(S/S Refresh
Processor)
Maximum
Processor
ICC
S/S Refresh-
Processor
Line (150W)
8P+16E
Core
— — 307 A
4,5,6,7,1
1
IccMAX.App
(S/S Refresh
Processor)
Maximum
Processor
ICC .app
S/S Refresh-
Processor
Line (150W)
8P+16E
Core
— — 245 A
4,5,6,7,1
1
IccMAX
(S/S Refresh
Processor)
Maximum
Processor
ICC
S/S Refresh-
Processor
Line (150W)
8P+16E
Core
Extreme
Config
— — 400 A
4,5,6,7,1
1,17
IccMAX.App
(S/S Refresh
Processor)
Maximum
Processor
ICC .app
S/S Refresh-
Processor
Line (150W)
8P+16E
Core
Extreme
Config
— — 320 A
4,5,6,7,1
1,17
continued...
13.2.1
13.2.1.1
R
Intel
®
Core
™
, Xeon
™
6300 And Xeon
™
E 2400 Processors—Electrical Specifications
13
th
Generation Intel
®
Core
™
, Intel
®
Core
™
14
th
Generation, Intel
®
Core
™
Processor (Series 1) and (Series 2), Intel
®
Xeon
™
E
2400 Processor and Intel
®
Xeon
™
6300 Processor
Datasheet, Volume 1 of 2 May 2025
188 Doc. No.: 743844, Rev.: 015
Symbol Parameter Segment Minimum Typical Maximum Unit Note
1
IccMAX
(S Processor)
Maximum
Processor
ICC
S-Processor
Line (125W)
8P+16E/
8P+8E Core
— — 307 A
4,5,6,7,1
1
IccMAX.App
(S Processor)
Maximum
Processor
ICC .app
S-Processor
Line (125W)
8P+16E/
8P+8E Core
— — 245 A
4,5,6,7,1
1
IccMAX
(S Refresh
Processor)
Maximum
Processor
ICC
S Refresh-
Processor
Line (125W)
8P+16E/
8P+12E
Core
307 A
IccMAX.App
(S Refresh
Processor)
Maximum
Processor
ICC .app
S Refresh -
Processor
Line (125W)
8P+16E/
8P+12E
Core
245 A
IccMAX
(S Processor)
Maximum
Processor
ICC
S-Processor
Line (125W)
8P+16E
Core
Extreme
Config
— — 400 A
4,5,6,7,1
1,17
IccMAX.App
(S Processor)
Maximum
Processor
ICC .app
S-Processor
Line (125W)
8P+16E
Core
Extreme
Config
— — 320 A
4,5,6,7,1
1,17
IccMAX
(S Processor)
Maximum
Processor
ICC
S-Processor
Line (125W)
6P+8E
Core
— — 200 A
4,5,6,7,1
1
IccMAX.App
(S Processor)
Maximum
Processor
ICC .app
S-Processor
Line (125W)
6P+8E
Core
— — 170 A
4,5,6,7,1
1
IccMAX
(S Refresh
Processor)
Maximum
Processor
ICC
S Refresh-
Processor
Line (125W)
6P+8E
Core
— — 200 A
4,5,6,7,1
1
IccMAX.App
(S Refresh
Processor)
Maximum
Processor
ICC .app
S Refresh-
Processor
Line (125W)
6P+8E
Core
— — 170 A
4,5,6,7,1
1
IccMAX
(S Processor)
Maximum
Processor
ICC
S-Processor
Line (65W)
8P+16E/
— — 279 A
4,5,6,7,1
1
continued...
R
Electrical Specifications—Intel
®
Core
™
, Xeon
™
6300 And Xeon
™
E 2400 Processors
13
th
Generation Intel
®
Core
™
, Intel
®
Core
™
14
th
Generation, Intel
®
Core
™
Processor (Series 1) and (Series 2), Intel
®
Xeon
™
E
2400 Processor and Intel
®
Xeon
™
6300 Processor
May 2025 Datasheet, Volume 1 of 2
Doc. No.: 743844, Rev.: 015 189
