Processor Line Windows* 11 SV2 (2022 H2) Windows* 11 SV1 (2021 H2) Windows* 10 (21H2/22H2) Linux* OS Chrome* OS Windows* Server 2022 No (for Windows*10) E/E Refresh-Processor Line No Y es No Y es Note: Refer to OS vendor…

• Render Thermal Throttling

• Fan Speed Control with DTS

• Intel

Turbo Boost Technology 2.0 Power Control

• Intel

Dynamic Tuning technology (Intel

DTT)

Refer to Thermal Management on page 76 for more information.

Ball-out Information

For information on the ballout of S/S Refresh/E download the pdf, click on the

navigation pane and refer the spreadsheet, 743844-001_S_LGA_Ballout.xlsx.

For information on H, P, U, U Refresh and H Refresh processors ball information,

download the pdf, click

on the navigation pane and refer the spreadsheet,

743844-001_HPU_Ballout.xlsx.

For information on PX processor ball information, download the pdf, click

on the

navigation pane and refer the spreadsheet, 743844-001_PX_Ballout.xlsm.

For information on HX processor ball information, download the pdf, click

on the

navigation pane and refer the spreadsheet, 743844-001_HX_Ballout.xlsx.

Processor Testability

A DCI on-board connector should be placed, to enable 13

Generation Intel

Core

™

and Intel

Generation full debug capabilities.

For 13

Generation Intel

Core

™

and Intel

Generation processor lines, a Direct

Connect Interface Tool connector is highly recommended to enable lower C-state to

debug.

The processor includes boundary-scan for board and system level testability.

Operating Systems Support

Processor Line

Windows* 11 SV2

(2022 H2)

Windows* 11 SV1

(2021 H2)

Windows* 10

(21H2/22H2)

Linux* OS Chrome* OS

Windows* Server

2022

S/S Refresh/HX/HX

Refresh -Processor Line

Yes Yes No No

P/H/U/U Refresh/H

Refresh -Processor

Lines

Yes Yes Yes No

PX-Processor Line Yes (for Windows* 11) Yes Yes No

continued...

1.6

1.7

1.8

Introduction—Intel

Core

™

, Xeon

™

6300 And Xeon

™

E 2400 Processors

Generation Intel

Core

™

, Intel

Core

™

Generation, Intel

Core

™

Processor (Series 1) and (Series 2), Intel

Xeon

™

2400 Processor and Intel

Xeon

™

6300 Processor

May 2025 Datasheet, Volume 1 of 2

Doc. No.: 743844, Rev.: 015 25

Processor Line

Windows* 11 SV2

(2022 H2)

Windows* 11 SV1

(2021 H2)

Windows* 10

(21H2/22H2)

Linux* OS Chrome* OS

Windows* Server

2022

No (for Windows*10)

E/E Refresh-Processor

Line

No Yes No Yes

Note: Refer to OS vendor site for more information regarding latest OS revision support.

Terminology and Special Marks

Table 2. Terminology

Term Description

4K Ultra High Definition (UHD)

AES Advanced Encryption Standard

AGC Adaptive Gain Control

API Application Programming Interface

AVC Advanced Video Coding

BLT Block Level Transfer

BPP Bits per Pixel

CDR Clock and Data Recovery

CTLE Continuous Time Linear Equalizer

DDC Digital Display Channel

DDI Digital Display Interface for DP or HDMI/DVI

DSI Display Serial Interface

DDR4 Fourth-Generation Double Data Rate SDRAM Memory Technology

DDR5 Fifth-Generation Double Data Rate SDRAM Memory Technology

DPC DIMM per channel

DFE Decision Feedback Equalizer

DMA Direct Memory Access

DPPM Dynamic Power Performance Management

DMI Direct Media Interface

DP* DisplayPort*

DSC Display Stream Compression

DSI Display Serial Interface

DTS Digital Thermal Sensor

ECC Error Correction Code - used to fix DDR transactions errors

eDP* Embedded DisplayPort*

continued...

1.9

Intel

Core

™

, Xeon

™

6300 And Xeon

™

E 2400 Processors—Introduction

Generation Intel

Core

™

, Intel

Core

™

Generation, Intel

Core

™

Processor (Series 1) and (Series 2), Intel

Xeon

™

2400 Processor and Intel

Xeon

™

6300 Processor

Datasheet, Volume 1 of 2 May 2025

26 Doc. No.: 743844, Rev.: 015

Term Description

EU Execution Unit in the Graphics Processor

FIVR Fully Integrated Voltage Regulator

GSA Graphics in System Agent

GNA Gauss Newton Algorithm

HDCP High-Bandwidth Digital Content Protection

HDMI* High Definition Multimedia Interface

IMC Integrated Memory Controller

Intel

Technology

64-bit memory extensions to the IA-32 architecture

Intel

DPST Intel

Display Power Saving Technology

Intel

PTT Intel

Platform Trust Technology

Intel

TXT Intel

Trusted Execution Technology

Intel

Virtualization Technology. Processor Virtualization, when used in conjunction

with Virtual Machine Monitor software, enables multiple, robust independent software

environments inside a single platform.

Intel

VT-d

Intel

Virtualization Technology (Intel

VT) for Directed I/O. Intel

VT-d is a

hardware assist, under system software (Virtual Machine Manager or OS) control, for

enabling I/O device Virtualization. Intel

VT-d also brings robust security by providing

protection from errant DMAs by using DMA remapping, a key feature of Intel

VT-d.

ITH Intel

Trace Hub

IOV I/O Virtualization

IPU Image Processing Unit

LFM

Low Frequency Mode. corresponding to the Enhanced Intel SpeedStep

Technology’s

lowest voltage/frequency pair. It can be read at MSR CEh [47:40].

LLC Last Level Cache

LPSP Low-Power Single Pipe

LSF

Lowest Supported Frequency.This frequency is the lowest frequency where

manufacturing confirms logical functionality under the set of operating conditions.

LTR

The Latency Tolerance Reporting (LTR) mechanism enables Endpoints to report their

service latency requirements for Memory Reads and Writes to the Root Complex, so

that power management policies for central platform resources (such as main

memory, RC internal interconnects, and snoop resources) can be implemented to

consider Endpoint service requirements.

MCP

Multi-Chip Package - includes the processor and the PCH. In some SKUs, it might

have additional On-Package Cache.

MFM

Minimum Frequency Mode. MFM is the minimum ratio supported by the processor and

can be read from MSR CEh [55:48].

MLC Mid-Level Cache

MPEG

Motion Picture Expert Group, international standard body JTC1/SC29/WG11 under

ISO/IEC that has defined audio and video compression standards such as MPEG-1,

MPEG-2, and MPEG-4, etc.

NCTF

Non-Critical to Function. NCTF locations are typically redundant ground or non-critical

reserved balls/lands, so the loss of the solder joint continuity at end of life conditions

will not affect the overall product functionality.

continued...

Introduction—Intel

Core

™

, Xeon

™

6300 And Xeon

™

E 2400 Processors

Generation Intel

Core

™

, Intel

Core

™

Generation, Intel

Core

™

Processor (Series 1) and (Series 2), Intel

Xeon

™

2400 Processor and Intel

Xeon

™

6300 Processor

May 2025 Datasheet, Volume 1 of 2

Doc. No.: 743844, Rev.: 015 27
