Network operation and remote control R&S ® LCX Series 179 User Manual 1 179.2260.02 ─ 08 T o mount the FTP network address string to the file explorer: 1. Open the file explorer on the controller PC. 2. Connect to th…
Network operation and remote control
R&S
®
LCX Series
178User Manual 1179.2260.02 ─ 08
9.
Turn "DHCP & Auto IP".
The R&S LCX indicates the IP address that you can use for accessing the instru-
ments file system over the FTP protocol, see Accessing the file system remotely
over a file explorer.
Accessing the file system remotely over a file explorer
Prerequisite: the controller PC and the R&S LCX are connected in a LAN, see "Estab-
lishing the LAN connection" on page 24.
For FTP access, you need a URI address string and you must enter the user name
and password of the instrument. For security reasons, we recommend that you assign
a dedicated user-specific password in the "FTP Remote-Access" dialog before con-
necting to the instrument. See Section 10.3.4, "FTP settings", on page 164.
This example refers to an application on a Windows client.
To enable the FTP file transfer connection, follow the instructions as given under Ena-
bling the FTP service for remote access.
1. Open a file explorer on the controller PC, e.g. the Windows Explorer, or the Internet
Explorer.
2. To connect to the FTP server, enter the FTP address string of the R&S LCX in the
address bar.
The address string follows the syntax:
ftp://<ip address or hostname>[:port], e.g.
ftp://192.168.0.128:5678
A "Log On As" dialog opens that prompts you to enter the user name and pass-
word of the instrument.
Note: If you use a port number different from the default port 21, you must add this
number to the address string, e.g. ftp://192.168.0.128:5678.
Tip: As an alternative, you can add the login credentials directly in the address
string:
ftp://<user name>:<password>@<ip address or hostname>[:port],
e.g. ftp://LCR200:<password>@192.168.0.128:5678
3. Confirm with enter.
The file system of your LCR meter appears.
You can browse the content of the internal and externally connected USB memory
device, and upload and download files as known from file manager functions.
Mounting the FTP connection for quick access
For quick access to the instrument without logging in, you can assign the FTP remote
network address connection to the file explorer:
This example refers to the file manager application on a Windows client.
Operating the R&S
LCX remotely
Network operation and remote control
R&S
®
LCX Series
179User Manual 1179.2260.02 ─ 08
To mount the FTP network address string to the file explorer:
1. Open the file explorer on the controller PC.
2. Connect to the R&S LCX file system as described in Accessing the file system
remotely over a file explorer.
3. Select the computer name directory of your controller PC, e.g. "This PC".
4. In the ribbon bar of the "Computer" tab, select "Add a network location".
The "Add Network Location" wizard opens.
5. Follow the steps of the wizard:
a) Select "Choose a custom network location".
b) In step "Specify the location of your web site", enter the FTP address string,
e.g. ftp://LCR200:<password>@192.168.0.128:5678.
c) Assign a user name for the directory, e.g. _LCR200_FTP, if necessary.
d) For immediate access, enable the "Open this network location ...." checkbox.
e) Confirm with "Finish".
The available file directories of the instrument appear under the mounted directory
in the navigation tree. You can browse in the instruments file system and upload or
download files.
Note: The address string in the example contains the login credentials and thus
directly accesses the instrument's file system when reconnecting.
To protect the instrument from unauthorized access, you can also set up only the
FTP network address, and thus explicitly require the login for each connection.
Stopping the remote FTP file access
To terminate FTP file access:
1.
NOTICE! Risk of data loss. Terminating FTP file access during file transfer can
impact a file and lead to data loss. Also, when the connection to the controller PC
is interrupted accidentally.
Operating the R&S
LCX remotely
Network operation and remote control
R&S
®
LCX Series
180User Manual 1179.2260.02 ─ 08
Wait until an ongoing transfer process has finished.
2. Close the FTP client application.
3. To reconnect, proceed as described above.
