iii
Safety instructions
2. Warning label format and mark description
2.1 Warning label format
As shown below, a warning label indicates the degree of hazard by means of a signal word and the color of the
signal word panel. A mark and a pictogram are also used to emphasize the message. Basically, labels attached
to the outside of machines are in 4 languages (English, Chinese, Korean and Japanese) while labels attached to
the inside of the device are only a pictogram.
Pinch or crush hazard.
WARNING
90K41-000380
Warning label format
Warning message and mark (pictogram) example
Signal word
Safety alert symbol
Signal word panel
Message
Mark and pictogram
Danger : Red
Warning : Orange
Caution : Yellow
93206-L0-00
2.2 Meaning of marks
The following 3 types of marks are used on warning labels. Each mark has its own meaning and is typically
used with a pictogram to emphasize the message.
Warning mark
Usage examples
Prohibition mark Instruction mark
WARNING WARNINGWARNING
Mark and pictogram
Marks and examples used with pictogram
93207-L0-00
Definition Shape/Color
Meaning of the above
examples
Warning
Indicates a hazard, how to
avoid the hazard, and potential
consequences of ignoring the
warning.
Yellow triangle with black
border. Pictogram is black on
yellow.
Risk of electrical shock
Prohibition
Indicates a prohibited action to
avoid the potential hazard.
Red circle with slash. Pictogram
is black and located behind
slash.
Do not modify or disassemble
safety cover switch.
Instruction
Indicated an action that must
be taken to avoid the potential
hazard.
Blue circle. Pictogram is white
on blue.
Read the manual to understand
procedure before starting
operation.
iv
Safety instructions
3. Pasting Position of Warning Labels and Meaning of Labels
3.1 Pasting position of warning labels
w
WARNING
DO NOT PEEL OFF OR COVER THE WARNING LABELS. IF THE WARNING LABELS BECOME DIRTY OR DAMAGED, AND
BECOME UNREADABLE, CONTACT YAMAHA OR AGENT TO OBTAIN LABELS, AND PASTE THE NEW LABEL ON THE SAME
POSITION.
Pasting position of warning labels
YSi-SP
Emergency stop button
■ Conveyor opening (right and left)
■ Main switch
■ Cover inner side
■ Power connection terminals
(Cover inner side)
23001-KMN-10
v
Safety instructions
Pasting position of warning labels
YSi-SP Extension conveyor unit type (option)
Emergency stop button
■ Conveyor opening (right and left)
■ Main switch
■ Power connection terminals
(Cover inner side)
■ Cover inner side
■ Extension Conveyor unit
■ Extension Conveyor unit
23002-KMN-00
