1-8 1 Over view and maintenance of machine 4.3 Name of each par t Name of each part Tower light XY unit Camera Treatment cone Z-axis light source unit Z-axis offset XY unit LED illumination Conveyor Emergency stop button…
1-7
1
Overview and maintenance of machine
4.2 System configuration
System configuration
PC
Communications
(front and back)
Camera
Tower lightConveyor
Data station
Lighting system
Mouse
Keyboard
Operation panel
Safety switch, Emergency stop
XYZ table
Sequencer
control panel
23104-KMN-00
1-8
1
Overview and maintenance of machine
4.3 Name of each part
Name of each part
Tower light
XY unit
Camera
Treatment
cone
Z-axis light
source unit
Z-axis offset
XY unit
LED
illumination
Conveyor
Emergency stop button
Operation panel
Keyboard
Breaker
Control panel
Control PC
23105-KMN-00
Name of each part
YSi-SP Extension conveyor unit type (option)
Extension Conveyor unit
Extension Conveyor unit
23113-KMN-00
1-9
1
Overview and maintenance of machine
4.4 Work size which can be inspected by this machine
■
Work size
Outline (L * W) 50 * 50 to 510 * 460 mm
Weight (MAX) 3.0 kg or less
Board thickness 0.3 to 5.0 mm
4.5 Conditions of work shape
■
Conditions of work shape
Warp of the work
Short
interval
0.3/40 mm or less
Fluctuation
of the entire
interval
±5.0 mm or less
Height of cream solder (MAX)
400 μm or less (Resolution: at 25 um/12.5 um)
300 μm or less (Resolution: at 20 um/10 um)
300 μm or less ((Resolution: at 15 um/7.5 um)
Material and
color of board
Material of
substrate
Glass epoxy, paper phenol, polyimide film base
*Consult with CKD for alumina (ceramic) substrate.
Solder resist
color
Solder resist color shall not be dark color like black.
Consult with CKD for light color.
4.6 Operating environment
■
Operating environment
Room temperature 25 °C to 35 °C (68 °F to 95 °F)
Humidity 50% to 70% (without condensation)
Altitude Average altitude 1000 m or less
Overvoltage section III
Pollution level 3
4.7 Noise value
65dB (A)
Operating Condition : Full load Measuring Method : According to clause 1. 7. 4. 2 of Machinery Directive
2006/42/EC
4.8 Transportation, storage environment
By design or by taking proper preventive measure, electrical equipment can withstand the influence of
temperatures for the transportation and storage temperatures from -25 °C to + 55 °C (-13 °F to 131 °F).
Appropriate measures must be taken to protect the equipment from damages by humidity, vibration, and
impact.
4.9 Rules for design reference
Machinery Directive:
EN ISO12100, EN ISO13849, EN 60204-1, EN ISO13857 etc
