2-95
2
Operation
I/O Comment
2012
Inspection conveyor width adjustment axis home position error
The home position determination action of the inspection conveyor width adjustment axis is not
finished in the predetermined time. Press the RESET switch to reset.
2013
Inspection conveyor width adjustment axis positioning error
The width adjustment action of the inspection conveyor is not finished in the predetermined time.
Press the RESET switch to reset.
2015
Loading conveyor width adjustment (narrow) overrun
The action range detection sensor (normal upon active state) of the loading conveyor width
adjustment axis pulse motor is turned off.
Press the RESET switch to reset.
2016
Loading conveyor width adjustment axis home position error
The home position determination action of the loading conveyor width adjustment axis is not
finished in the predetermined time.
Press the RESET switch to reset.
2017
Loading conveyor width adjustment axis positioning error
The width adjustment action of the loading conveyor is not finished in the predetermined time.
Press the RESET switch to reset.
2019
Unloading conveyor width adjustment (narrow) overrun
The action range detection sensor (normal upon active state) of the unloading conveyor width
adjustment axis pulse motor is turned off.
Press the RESET switch to reset.
201A
Unloading conveyor width adjustment axis home position error
The home position determination action of the unloading conveyor width adjustment axis is not
finished in the predetermined time.
Press the RESET switch to reset.
201B
Unloading conveyor width adjustment axis positioning error
The width adjustment action of the unloading conveyor is not finished in the predetermined time.
Press the RESET switch to reset.
201C
Loading conveyor width adjustment error (pass sensor)
The "pass" sensor is turned on at the start of width adjustment action of the loading conveyor.
201D
Loading conveyor width adjustment error (confirmation sensor)
The "confirmation" sensor is turned on at the start of width adjustment action of the loading
conveyor.
201E
Unloading conveyor width adjustment error (pass sensor)
The "pass" sensor is turned on at the start of width adjustment action of the unloading conveyor.
201F
Unloading conveyor width adjustment error (confirmation sensor)
The "confirmation" sensor is turned on at the start of width adjustment action of the unloading
conveyor.
2028
Width setting error / Take-in sensor ON
The load side sensor (PHRX004) was turned on while adjusting width. Please confirm whether
there are PCB etc., and push the Reset button.
2029
Width setting error / Take-out sensor ON
The unload side sensor (PHRX005) was turned on while adjusting width. Please confirm whether
there are PCB etc. , and push the Reset button.
2-96
2
Operation
I/O Comment
2031
PCB clamp take-in sensor ON
Intake-side sensor turned on during width setting/clamping. Press the Reset button after
confirming that PCBs, etc. are note present.
2032
PCB clamp take-out sensor ON
Offtake-side sensor turned on during width setting/clamping. Press the Reset button after
confirming that PCBs, etc. are not present.
203B
Abnormality in return stroke of PCB clamp
PCB clamp did not activate with the preset period of time.
Please confirm whether there is foreign matter, and depress the conveyer.
203C
Abnormality on PCB clamp exit side
PCB clamp did not activate with the preset period of time. Check to see:
if foreign matter is caught between parts
2040
Insp conveyor PCB load/arrival sensor not ON
"Failure in loading of PCB. The ""arrival"" sensor is not turned on in the predetermined time.
Remove the PCB from the conveyor and press the RESET switch to reset.
2041
Inspection conveyor PCB loading error 2
Failure in loading of PCB. The "unloading" sensor is turned on when the PCB is loaded. Remove
the PCB from the inspection conveyor and press the RESET switch to reset.
2042
Inspection conveyor PCB loading error 3
Failure in loading of PCB. The "loading" sensor is turned on after the PCB is loaded. Remove the
PCB from the "loading" sensor section and press the RESET switch to reset.
2044
Inspection conveyor PCB unloading error 1
Failure in unloading of PCB. The "unloading" sensor is not turned on in the predetermined time.
Remove the PCB from the conveyor and press the RESET switch to reset.
2045
Inspection conveyor PCB unloading error 2
Failure in unloading of PCB. The "unloading" sensor is not turned off in the predetermined time.
Remove the PCB from the conveyor and press the RESET switch to reset.
204D
Inspection conveyor PCB unloading error 1
The "arrival" sensor is turned on at the start of width adjustment action of the inspection
conveyor.
Adjust the conveyor width when the "arrival" sensor is turned off.
2050
Loading conveyor loading error 1
Failure in loading of PCB. The "confirmation" sensor is not turned on in the predetermined time.
Remove the PCB from the loading conveyor and press the RESET switch to reset.
2053
Loading conveyor ejection error
Failure in unloading of PCB. The "confirmation" sensor is not turned off in the predetermined
time. Remove the PCB from the loading conveyor and press the RESET switch to reset.
2054
Unloading conveyor loading error 1
Failure in loading of PCB. The "confirmation" sensor is not turned on in the predetermined time.
Remove the PCB from the unloading conveyor and press the RESET switch to reset.
2057
Unloading conveyor ejection error
Failure in unloading of PCB. The "confirmation" sensor is not turned off in the predetermined
time.
Remove the PCB from the unloading conveyor and press the RESET switch to reset.
2058
Loading conveyor safety cover opening fault (width adjustment failure)
The safety cover of the loading conveyor opened at the start of conveyor width adjustment.
Close the safety cover of the loading conveyor.
2059
Unloading conveyor safety cover opening fault (width adjustment failure)
The safety cover of the unloading conveyor opened at the start of conveyor width adjustment.
Close the safety cover of the unloading conveyor.
2-97
2
Operation
I/O Comment
205A
Loading conveyor safety cover opening fault (time-up)
Home position determination, automatic operation or Y-table travel does not start because the
safety cover of the loading conveyor is open.
Close the safety cover of the loading conveyor.
205B
Unloading conveyor safety cover opening fault (time-up)
Home position determination, automatic operation or Y-table travel does not start because the
safety cover of the loading conveyor is open.
Close the safety cover of the loading conveyor.
205C
Loading conveyor width adjustment error (pass sensor)
The "pass" sensor is turned on at the start of width adjustment action of the loading conveyor.
Press the RESET switch to reset.
205D
Loading conveyor width adjustment error (confirmation sensor)
The "confirmation" sensor is turned on at the start of width adjustment action of the loading
conveyor.
Press the RESET switch to reset.
205E
Unloading conveyor width adjustment error (pass sensor)
The "pass" sensor is turned on at the start of width adjustment action of the unloading conveyor.
Press the RESET switch to reset.
205F
Unloading conveyor width adjustment error (confirmation sensor)
The "confirmation" sensor is turned on at the start of width adjustment action of the unloading
conveyor.
Press the RESET switch to reset.
206B
Abnromality in return stroke of PCB pusher
PCB pusher did not return to position within the preset period of time. Check to see:
i) if foreing matter is not caught between parts.
206F
PLC Battery Error
PLC Battery is low. Please Change Batttery
