Contents 1. Preface 1-1 2. About this manual 1-2 3. Before Use 1-3 3.1 Power supply specifications 1-3 3.2 Caution items when installing 1-3 3.3 Installation 1-4 3.3.1 Level adjustment 1-4 4. Machine Overview 1-5 4.1 Mec…
ix
Safety instructions
5. Other Caution Items
5.1 Caution on operation
■
Setting values
c
CAUTION
This machine operates on various setting values. In case of failure, make a backup or write down each setting value.
■
Restoration from power outage, emergency stop, and failure
c
CAUTION
Malfunction may occur in case of power outage, emergency stop, and device failure. After restoration, always
perform a general inspection.
5.2 Caution on maintenance
■
Disassembly of devices
c
CAUTION
Please note that we are not responsible for damages caused by repair, disassembly, remodeling, etc. by third parties
other than YAMAHA and agents.
■
Operation part
w
WARNING
DO NOT OPEN THE SAFETY COVER DURING OPERATION.
WHEN OPENING THE SAFETY COVER FOR REPLACEMENT AND INSPECTION, PERFORM ONLY AFTER SHUTTING DOWN THE
POWER SOURCE AND VERIFY THAT THE DEVICE IS STOPPED.
■
Electrical device
w
WARNING
INSIDE THE CIRCUIT REMAINS CHARGED FOR A WHILE EVEN AFTER THE POWER SOURCE IS SHUTDOWN. WHEN HANDLING
THE CHARGED PART FOR A MAINTENANCE WORK, WAIT FOR 5 MINUTES OR MORE AFTER THE PRIMARY POWER SOURCE IS
SHUT-DOWN COMPLETELY, AND THEN PERFORM YOUR WORK.
w
WARNING
WHEN PERFORMING MAINTENANCE AND ADJUSTMENT WORK OF THE DEVICE, CONDUCT AFTER MAKING SURE THERE ARE
NO PRODUCTS ON THE CONVEYOR.
THEN PUT THE COVER REMOVED FOR MAINTENANCE AND ADJUSTMENT BACK ON, AND TURN THE POWER BREAKER ON.
c
CAUTION
This machine uses various electronic equipment; therefore, when conducting a withstand voltage test and an
insulation test, make sure test voltage is not applied on this equipment.
■
Discarding personal computer
c
CAUTION
A lead battery is used for UPS in the personal computer. Discard it appropriately according to the regulations of your
area.
Contents
1. Preface 1-1
2. About this manual 1-2
3. Before Use 1-3
3.1 Power supply specifications 1-3
3.2 Caution items when installing 1-3
3.3 Installation 1-4
3.3.1 Level adjustment 1-4
4. Machine Overview 1-5
4.1 Mechanical specification 1-5
4.2 System configuration 1-7
4.3 Name of each part 1-8
4.4 Work size which can be inspected by this machine 1-9
4.5 Conditions of work shape 1-9
4.6 Operating environment 1-9
4.7 Noise value 1-9
4.8 Transportation, storage environment 1-9
4.9 Rules for design reference 1-9
5. Temporary measure for PLC/UPS failure 1-10
5.1 Pass Mode of PLC 1-10
5.1.1 PLC switch panel 1-10
5.1.2 Adjustment of the conveyor width 1-11
5.1.3 Explanation of switches 1-11
5.1.4 Operational procedure of forced PASS mode 1-11
5.2 Disabling UPS 1-12
Chapter 1 Overview and maintenance of machine
1-1
1
Overview and maintenance of machine
1. Preface
Thank you very much for purchasing the solder paste inspection machine, “YSi-SP”.
Before start operating the machine, always read this manual and appended manual carefully, and understand
the proper operational procedure and noted safety caution items.
Especially, always follow the safety caution items described in this manual. Also, if you are unsure of some
operational procedure, do not make a judgment by yourself, but refer to this manual again to check the
appropriate operational procedure. For questions and injuries, please contact below.
The safety caution items described in this manual are categorized as follows depending on the level of bodily
injuries, failure to the machine, and damages. Please always conduct safe operation.
■
Warning
w
WARNING
WHEN MISHANDLED, IT SHOWS THE CONTENTS THAT MAY CAUSE DEATH OR SERIOUS INJURIES.
THIS IS THE MOST IMPORTANT CAUTION ITEMS TO PROTECT THE OPERATORS, INSPECTORS, AND THOSE WHO DO REPAIR OF
THIS MACHINE.
■
Caution
c
CAUTION
When mishandled, it shows the contents that may cause injuries or physical damages.
This is the important caution items to prevent damage on the machine and data.
Please store in a safe place after reading this manual.
When ordering parts, always inform the serial number (Yxxxxx) printed in the nameplate of the machine.
