7. "Recall" Submenu

The "Recall" Window is provided with the following five buttons.

Fig. 2A7-1 "Recall" Window

The "Recall" submenu is provided with the following four buttons.

When a button is pressed, the corresponding window opens, enabling the operator

to select the required data.

Table 2A7-1

Buttons Description

Device Err

When pressed, the device error history is displayed.

Reference

Refer to "2. "Device Err" Window "in Chapter 5, for the details.

Comp Rcg Err

When pressed, the component recognition error history is displayed.

Reference

Refer to "3. "Comp Rcg Err "Window" in Chapter 5, for the

details.

Comp Err(Sens)

When pressed, the detected component posture error history is

displayed.

Reference

Refer to "4. "Comp Err(Sens)" Window" in Chapter 5, for the

details.

Mach Info

When pressed, the machine information history is displayed.

Reference

Refer to "5. "Mach Info" Window" in Chapter 5, for the details.

Graphic

Development
