2OM-1733 4-2-13 [12] H:Meas. Error Each text box shows the total times of measured value error in each feeder. [13] K:Copla. Error Each text box shows the total times of detected "Coplanarity Error" in each fee…
2OM-1733
4-2-12
The "FdrMng." tab sheet is divided further into several tabs and each tab sheet
shows the handling errors per feeder on each individual feeder bases.
When each tab is pressed, the corresponding tab sheet appears.
[1] Feeder No.
Shown are the feeder Nos.
[2] Total Noz. Usage
Each text box shows the number of pickup actions for each individual
nozzles.
[3] Total Errors
Each text box shows the total number of errors detected in [5] through [13].
[4] Rate of Error (%)
Each text box shows the percentage of the total number of errors per the
number of picked components.
[5] A:Comp. Missing
Each text box shows the total number of missing components detected by the
linear measure detection sensor for each individual feeders.
[6] B:Comp. Missing
Each text box shows the total number of missing components detected
through recognition operation for each individual feeders.
[7] C:Comp. Vertical
Each text box shows the total number of vertical component errors detected
by the linear measure detection sensor for each individual feeders.
[8] D:Comp. Recog.
Each text box shows the total number of errors detected through recognition
operation for each individual feeders.
[9] E:Comp. Thick
Each text box shows the total number of errors in component thickness
detected by the linear measure detection sensor for each individual feeders.
[10] F:Pick-up Diff
Each text box shows the total times of pick-up deviation in each feeder in the
recognition processing.
[11] G:Comp. Posture
Each text box shows the total times of front/rear judgement error or polarity
error in each feeder in the recognition processing.
1212-002
2.2 "FdrMng." Tab Sheet
2OM-1733
4-2-13
[12] H:Meas. Error
Each text box shows the total times of measured value error in each feeder.
[13] K:Copla. Error
Each text box shows the total times of detected "Coplanarity Error" in each
feeder. This error is detected in the option attachment.
[14] Shrtg. of Comp.
Each text box shows the total times of detected "Component Shortage" in
each feeder.
[15] Update Date & Time for Each Feeder
Each test box shows the update date & time for each feeder.
1212-002
2.2 "FdrMng." Tab Sheet
2OM-1733
4-2-14
2.3 "NozMng." Tab Sheet
The corresponding tab sheet enables the operator to view the nozzle management
data.
When the [NozMng.] tab is pressed in the "MNG.DT." window, the following tab
sheet appears inside the window.
[5] [6] [7][2][1] [3] [4] [8] [9]
[10]
Fig. 2D2-9 "NozMng." Tab Sheet (1/2)
[11] [12] [13]
[14]
Fig. 2D2-10 "NozMng." Tab Sheet (2/2)
