1. Outline of "Recall" Window
1. Outline of "Recall" Window
The submenu for the "Recall" window is displayed.
Fig. 2E1-1 "Recall" Window
The "Recall" menu is provided with the following four buttons.
When a button is pressed, the corresponding window opens.
Table 2E1-1
Buttons Description
Device Err
When pressed, the "Device Err" window appears, enabling the operator
to check the device error logs.
Comp Rcg Err
When pressed, the "Comp Rcg Err" window appears, enabling the
operator to check the logs of the component recognition errors.
Comp Err(Sens)
When pressed, the "Comp Err(Sens)" window appears, enabling the
operator to check the logs of the component posture errors detected by
the linear measure sensor.
Mach Info
The logs of the machine information will be displayed.
