01 12-003 C h a pt e r 3 2 - 6 Tg0252-PM-SO 4. Troubleshooting after Error Message Check “Section D Indication” (error code), “Section A Indication”, “Section B Indication” and “Section C Indication” at the ERROR display…
0005-001 Chapter 3 2-5 Tg0252-PM-SO
4. Troubleshooting after Error Message
ERROR Display for the Main Body
ERROR Display for the Multi-Layer Tray Feeder
[ ERROR Indication Examples ]
Section A: Shows an ERROR message.
Section B: Shows the ERROR description.
Section C: Shows the Cause and Remedy Guide for the Error.
Section D: Indicates an ERROR code consisting of 6 digits.
4. Troubleshooting after Error Message
Fig. 3.3
D
Fig. 3.4
C
B
A
B
A
C
0112-003 Chapter 3 2-6 Tg0252-PM-SO
4. Troubleshooting after Error Message
Check “Section D Indication” (error code), “Section A Indication”, “Section B
Indication” and “Section C Indication” at the ERROR display: remedy the
device by referring to the following trouble shooting guide.
(Cause 1) Motor encoder section may be defective.
(Cause 2) Encoder cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Turn off the power and check for loose connections between the sections of the motor and
signal cable.
(2) Re-start.
(3) If the device can’t be reset even after the above check, contact our service personnel because
the signal cable may be broken or the motor may be defective.
Error Code Display A Display B
(Cause 1) The sensor may be defective.
(NEXT PAGE)
0D 01 01 BPC-AXIS ORIGIN ENCORDER ORIGIN WAS NOT DETECTED.
0D 01 02 BPC-AXIS ORIGIN ORIGIN (SLIDE) WAS NOT DETECTED.
;BPH163 E / R
*1: Shows an ERROR code.
The description is shown according to the order of the code No.
*2: Shows the description of “Section A Indication” for the ERROR code.
*3: Shows the description of “Section B Indication” for the ERROR code.
*4: Shows the “Cause” and “Remedy” for the ERROR code.
Note: The description might be different from that in the “CAUSE AND REM-
EDY” section on the error display.
*5: When the description is continued on to the next page, “NEXT PAGE” is
shown.
*6: Icons
: Indicates the cause of the error.
: Indicates the work procedure.
: Contact our service personnel.
: Shows the teaching function.
*1 *2 *4 *3
*2
*6
*5
*3
Indication Example
0112-003 Chapter 3 2-7 Tg0252-PM-SO
4. Troubleshooting after Error Message
11 01 01 TV1-AXIS ORIGIN UNIDENTIFIED CARRIAGE DETECTED ON TRAVERSE.
11 01 02 TV1-AXIS ORIGIN TRAVERSE #1 ORIGIN [BPH251] SENSOR MAY BE
DEFECTIVE.
Error Code Display A Display B
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
(Cause 1) Is there an unstable pallet on the traverse?
(Cause 2) Is the traverse projecting from the pallet?
(Cause 3) Did you used the specified pallet?
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Check the cause of the error.
(Check the traverse).
(3) Press the [RESET] button and cancel the error indication.
(4) Turn off the power as required and remove the pallet on the traverse.
(Reset Procedure in the case of Cause 3)
Reset Procedure
(1) Use the specified pallet.
ORIGIN IS NOT SET FOR THIS AXIS.
(Cause 1) Did you zero the traverse before starting it?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
11 01 03 TV1-AXIS ORIGIN
