Checking Item 01 12-002 18 Tg0252-PM-SO Example: Lowered Accuracy caused by the Installation without using a level Example: Falling due to Insufficient Floor Strength Damage Inaccuracy CAUTION CAUTION

Checking Item

0112-002 17 Tg0252-PM-SO

Example: Power Supply Error/Imperfect Contact/Wiring Error

Example: Impact during Relocation or Transportation

Example: Abnormalities caused by Noise

Smoking/

Injection

Inaccuracy

Collision

CAUTION

Run Away

Breakdown

Checking Item

0112-002 18 Tg0252-PM-SO

Example: Lowered Accuracy caused by the Installation

without using a level

Example: Falling due to Insufficient Floor Strength

Damage

Inaccuracy

CAUTION

Name of Each Section

Tg0252-PM-SO

Operation Monitor

(Touch Screen)

Elevator

Center Cover

Upper

Door

Lower

Door

Lower Cover

[UPPER DOOR ELECTRO-

MAGNETIC LOCK] Switch

[U READY] Button

[LOWER DOOR ELECTRO-

MAGNETIC LOCK] Switch

[L READY] Button

Multi-Layer Tray Feeder (FP-5021L)

This device consists of the multi-layer tray feeder body, maga-

zines, tray fixing metal and pallets, etc.

0112-003 19

Pallet (MP-5050)Tray Fixing Metal (MF-5050L)

Grips of Magazine

Magazine (MG-5050L)

Magazine Door Fixture

Magazine Door

Grip

Grips of Magazine

Front

Back

Roller

Anchor Bolt

Lever

Clamping Claw
