1. Basic Precautions Tg0252-PM-SO The following precautions are particularly important for safe use of this device. Read and understand these precautions carefully for safe use of the device. Refer to "Precaution In…
Name of Each Section
Tg0252-PM-SO
Operation Monitor
(Touch Screen)
Elevator
Center Cove
r
Upper
Door
Lower
Door
Lower Door
[UPPER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[U READY] Button
[LOWER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[L READY] Button
0112-002 20
Multi-Layer Tray Feeder (FP-5021R)
Grips of Magazine
Magazine (MG-5050R)
Magazine Door
Grips of Magazine
Grip
Magazine Door Fixture
Grips of Magazine
Tray Fixing Metal (MF-5050R)
Roller
Anchor Bolt
Lever
Clamp Claw
Pallet(MP-5050)
Front
Back
1. Basic Precautions
Tg0252-PM-SO
The following precautions are particularly important for safe use of this
device. Read and understand these precautions carefully for safe use of
the device.
Refer to "Precaution Indication for Safety" for description of symbols.
1. Basic Precautions
1.1 Safety Check before Powering
• Make sure that no person (or any part of a person's body or
clothing) or other thing touches any moving part of the device.
After careful safety check, power on and start up the device.
Safety Check around the Device
0112-002 21
Compulsion
Safety Check
1. Basic Precautions
Tg0252-PM-SO
••
••
• Dangers resulting from Inadequate Safety
Check
• Parts of persons or things might be caught and rolled in the
moving part of the device, which might cause injury or break-
down.
0112-001 22
Example: Inadequate Safety Check
Breakdown
CAUTION
Example: Inadequate Safety Check
Injury
WARNING
