6. Other Precautions
Tg0252-PM-SO
6. Other Precautions
Follow the instructions below for handling of each section.
6.1 Precautions in Handling the Multi-Layer Tray Feeder
The figure shows the multi-layer tray feeder (FP-5021L).
The multi-layer tray feeder (FP-5021R) has the same structure as above.
5501 12-001
CAUTION
CAUTION
Precautions in Closing or Opening Upper Door
or Lower Door
Precautions in Mounting the Magazine
Precautions when Removing Elevator
Middle Stage Cover or Lower Stage Cover
Keep hands clear during device operation.
Your hand might be caught in a moving part
and so be injured.
Do not defeat the interlock function.
Part of your body might be caught by a moving part,
which might cause injury or breakdown.
Do not forget to put the magazine stopper in place,
otherwise it might move during operation,
causing a collision.
Do not bump the magazine, otherwise,
components might jump out of the tray
and enter the machine, with resultant breakdown.
Only remove the cover after turning off the power and air supply.
Inside the elevator are high voltage power sources and moving sections,
which might cause injury or electric shock.
Prohibition
(Do not Defeat Interlocks)
6. Other Precautions
Tg0252-PM-SO
6.2 Precautions in Handling the Magazine
The figure shows the magazine L (MG-5050L).
The magazine R (MG-5050R) has the same structure as the above.
01 12-001 56
Precautions in Closing or Opening the Magazine Door
Press the black circle section to close the magazine door securely;
otherwise the magazine door might open during operation and cause collision.
Precautions in Handling the Magazine
When the magazine is to be mounted on the device, do not mount it
carelessly; otherwise components might jump out from the tray, causing
breakdown.
CAUTION
CAUTION
