0112-001 Chapter 3 2-40 Tg0252-PM-SO
4. Troubleshooting after Error Message
13 06 14 EV1-AXIS INTERLOCK INCORRECT PALLET DETECTED ABOVE DRAWN
STEP.
13 07 01 MAGAZINE CONNECTION UPPER MAGAZINE CONNECTION NOT COMPLETED
WITHIN SPECIFIED TIME.
Error Code Display A Display B
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
13 07 02 MAGAZINE CONNECTION LOWER MAGAZINE CONNECTION NOT COMPLETED
WITHIN SPECIFIED TIME.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
13 08 01 POWER ON MONITOR CIRCUIT BREAKER [Q501] NOT DETECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
0112-001 Chapter 3 2-41 Tg0252-PM-SO
4. Troubleshooting after Error Message
13 08 02 POWER ON MONITOR ELEVATOR SAFETY RELAY [K501] NOT DETECTED.
13 08 03 POWER ON MONITOR SERVO POWER ON CHECK #1 [KM502] NOT DE-
TECTED.
Error Code Display A Display B
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
13 08 04 POWER ON MONITOR SERVO POWER ON CHECK #2 [KM501] NOT DE-
TECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
13 08 05 POWER ON MONITOR TRAY TYPE CODE #1 NOT CONNECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
13 08 06 POWER ON MONITOR TRAY TYPE CODE #2 NOT CONNECTED.
0112-001 Chapter 3 2-42 Tg0252-PM-SO
4. Troubleshooting after Error Message
14 01 01 EV2-AXIS ORIGIN CARRIAGE JERKED OUT OF MAGAZINE DETECTED.
14 01 02 EV2-AXIS ORIGIN ELEVETOR #1 SENSOR MAY BE DEFECTIVE.
Error Code Display A Display B
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
TRAVERSE #1 MIDDLE ORIGIN [BPH258] NOT DE-
TECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] button to cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device can’t be reset after the above procedure, contact our service personnel.
14 01 03 EV2-AXIS ORIGIN
(Cause 1) The pallet is projecting toward the side of the machine.
(Cause 2) The [BPH586] sensor light is shielded.
(Cause 3) The [BPH586] sensor is not adjusted correctly.
(Cause 4) The [BPH586] sensor is broken.
(Reset Procedure in the case of Causes 1, 2, 3, and 4)
Reset Procedure
(1) Press the [CLEAR ALARM] key to stop the buzzer sound.
(2) Press the [RESET] key and cancel the error mode.
(3) Press the [ZERO] button to return all axes to their original positions. Continue the production
according to the “WARM Start Operation Procedure”.
(4) If the device is not reset after the above procedure, contact our service personnel.
