Tg0252-PM-SO 991 1-001 C ha p t er 5 1- 9 2. Electrical Circuit Diagrams

Tg0252-PM-SO

9911-001 Chapter 5 1-8

2. Electrical Circuit Diagrams

Tg0252-PM-SO

9911-001 Chapter 5 1-9

2. Electrical Circuit Diagrams

Chapter 5 1-10 Tg0252-PM-SO

2.2 Elevator Circuit Diagrams

2. Electrical Circuit Diagrams

0112-004 A(M742WTL--2101)

Brake Power Source

Elevator Shaft

Encoder

Alarm

Brake

Elevator Shaft Origin

Emergency Stop

Alarm for Elevator Shaft

Brake

Elevator Shaft Overrun (+)

Elevator Shaft Limit (-)

Note.b

Note.c

Notes : (a) It shows the diagram within the dotted

lines is within the relay PCB.

(b) Use a pad of DS446 for the diode.
