5. Precautions in Installation Tg0252-PM-SO 01 12-001 48 5.5 Install somewhere where atmospheric tempera- ture and humidity is with in the specified range • Install the device where atmospheric temperature range is 20 ± …

5. Precautions in Installation

Tg0252-PM-SO

5.4 Install the device where there is no vibration

• Install the device where there is no vibration.

••

• Dangers caused by Vibration

• The device might fall or be damaged because of vibration.

• The device might break down because of vibration.

0112-001 47

Beware of Vibration

CAUTION

Example: Falling due to Vibration

Damage

Example: Breakdown due to Vibration

CAUTION

Breakdown

5. Precautions in Installation

Tg0252-PM-SO

0112-001 48

5.5 Install somewhere where atmospheric tempera-

ture and humidity is with in the specified range

• Install the device where atmospheric temperature range is 20 ±

10°C.

Also, install it where the humidity range is 20 to 80 % without

condensation.

••

• Dangers if atmospheric temperature or humid-

ity exceeds the specified range

• Smoke or fire might be caused by the device being at abnor-

mally high temperature.

CAUTION

Example: Smoke cause by abnormal heating

Smoking/

Injection

Atmospheric

Temperature

20 ± 10°C

Atmospheric

Humidity

30 to 80%

Beware of Temperature and Humidity

CAUTION

5. Precautions in Installation

Tg0252-PM-SO

5.6 Install the device somewhere where there is no

electrical noise

• Install the device somewhere where there is no electrical noise.

• Prevent noise with other equipment to avoid malfunction of the

device.

••

• Danger of noise near the device

• Device malfunction might be occur due to noise.

0112-001 49

Example: Malfunction caused by Noise

CAUTION

Collision

Compulsion

Noise Prevention Measures

Beware of Noise

CAUTION

Run Away
