5. Precautions in Installation
Tg0252-PM-SO
5. Precautions in Installation
5.1 Always contact our marketing department or sales
agency before relocation or resale of the device
• If you intend to relocate or resell the device, always consult our
marketing department or sales agency.
• If the destination of the relocation or resale of the machine is not
appropriate for operation environment, an accident or lowering
the machine function level might occur.
••
••
• Danger caused by the Operation without con-
sulting out marketing department or sales
agency before the Relocation or Resale
• Smoke or fire might occur due to the use of unspecified power
supply.
• Malfunction of the device might occur due to noise.
• Operator might have an electric shock due to short circuit.
0112-001 43
Example: Imperfect Contact/Wiring Error, etc.
WARNING
Short Circuit
Electric
Shock
Consult Beforehand
CAUTION
5. Precautions in Installation
Tg0252-PM-SO
0112-001 44
CAUTION
Example: Imperfect Contact/Wiring Error, etc.
Smoking/
Injection
Example: Abnormalities caused by Noise/Defeating of Interlocking, etc.
CAUTION
Collision
Run Away
5. Precautions in Installation
Tg0252-PM-SO
0112-001 45
5.2 Install the device somewhere where the floor
strength is adequate
• Install the device on the floor which can support the device
weight.
First floor is recommended. In the case of installing the
device on the floor other than the first floor, consult our
marketing department or sales agency.
••
••
• Dangers caused by Inadequate Floor Strength
Check
• If the device is installed on the floor with inadequate strength,
it might fall and be damaged.
CAUTION
Install the Device on the First Floor
First Floor
CAUTION
Example: Falling due to Inadequate Floor Strength
Damage
Beware of Floor Strength
CAUTION
