4. Precautions in Maintenance Tg0252-PM-SO 01 12-001 36 Example: Accident caused by work without powering off Electric Shock W ARNING

4. Precautions in Maintenance

Tg0252-PM-SO

4. Precautions in Maintenance

4.1 Turn off the power and air before maintenance

• During maintenance, check, or adjustment of oil filling or cleaning

the person in charge of maintenance should turn off the power

and air and proceed in the specified fashion.

••

• Dangers caused by the Maintenance without

Turning OFF the Power or Air

• Part of your body might be caught in the moving part of the

machine, which might cause injury.

• It might cause electric shock.

0112-001 35

Example: Accident caused by work without powering off

Injury

WARNING

Before Maintenance, turn the Power and Air OFF.

Turn the

Power OFF

Turn the Air

Supply OFF

Compulsion

4. Precautions in Maintenance

Tg0252-PM-SO0112-001 36

Example: Accident caused by work without powering off

Electric

Shock

WARNING

4. Precautions in Maintenance

Tg0252-PM-SO

4.2 Always Attached the Removed Cover

• If the cover has been removed for maintenance, always attach it

after maintenance.

Never start the machine with any cover removed.

••

• Dangers caused by Operation with Cover Re-

moved

• Part of your body might be caught in the moving part of the

machine, which might cause injury.

• It might cause electric shock.

• The moving part of the machine might collide with another

part.

• Smoke or fire might occur due to the contamination by a

foreign substance.

• Breakdown caused by contamination by foreign substance.

0112-001 37

Example: Accident caused by Operation with Cover Removed

WARNING

Injury

Always Attach the Removed Cover
