5. Precautions in Installation Tg0252-PM-SO 01 12-001 52 5.8 Install the device horizontally using a level • Install the device horizontally using a level. • • • • • Dangers caused by the device not being in stalled hori…

5. Precautions in Installation

Tg0252-PM-SO

0112-001 51

Example: Breakdown due to Corrosive Gas

CAUTION

Breakdown

5. Precautions in Installation

Tg0252-PM-SO

0112-001 52

5.8 Install the device horizontally using a level

• Install the device horizontally using a level.

••

• Dangers caused by the device not being in

stalled horizontally

• The device might fall due to vibration during an earthquake.

CAUTION

Using a Level

CAUTION

Example: Falling due to Inadequate Strength of Floor

Damage

5. Precautions in Installation

Tg0252-PM-SO

5.9 Install the device where there is no obstacle

• For easy maintenance, install the device only where there is no

obstacle.

••

• Dangers if installed where there are obstacles

• The device might bump into one of the surrounding obstacles,

with resultant damage.

0112-001 53

Install the device where there is no obstacle

Example: An obstacle collides with the device.

CAUTION

Damage

CAUTION
