Chapter 5 Manual mode 1. Manual mode main menu 5-3 2. I/O utility <3/4/A> 5-4 2.1 Input/output monitor <3/4/A1> .................................................................. 5-4 2.2 Feeder out monitor &l…
4
-72
Service Manual
Chapter 4
SED8013110
4
Machine adjust mode
3/3/B7 QUIT
Exits MCH_ADJUST mode without saving changes to the machine data.
The previous data stored in the file is reloaded for the operation.
c
CAUTION
All data temporarily stored in the RAM of the controller is deleted when this command
is run.
3/3/B0 SAVE & QUIT
Exits MCH_ADJUST mode after saving changes to the machine data. The
data temporarily stored in the RAM of the controller is now used for
subsequent operations.
Chapter 5
Manual mode
1. Manual mode main menu 5-3
2. I/O utility <3/4/A> 5-4
2.1 Input/output monitor <3/4/A1> ..................................................................5-4
2.2 Feeder out monitor <3/4/A2> .....................................................................5-6
2.3 Vacuum IN monitor <3/4/A4>....................................................................5-6
2.4 Change nozzle <3/4/A5> ...........................................................................5-7
2.5 Conveyor units <3/4/A0> ...........................................................................5-7
3. Servo control <3/4/B> 5-8
3.1 Select servo motor <3/4/B1> ......................................................................5-8
3.2 Running speed <3/4/B2>............................................................................5-8
3.3 Point move <3/4/B3> .................................................................................5-9
3.4 Initialize servo origin <3/4/B6> ..................................................................5-9
3.5 Exit from manual <3/4/B0> ......................................................................5-10
MANUAL mode allows running various commands which are useful
during adjustment of the machine. This chapter explains what these
commands do and how to read the input/output monitor.
5
-3
SED8013110
Service Manual
Chapter 5
5
Manual mode
1. Manual mode main menu
Manual (3/4/MANUAL) mode allows you to check the mechanical or
electrical on/off operation during adjustment. You can also manipulate the
YPU joystick to move a servo-controlled unit manually along its axis.
When you enter <3/4/ MANUAL> mode, the two command menu
windows <A/IO_UTILITY> and <B/SERVO_CONTROL> can be
selected. This section explains these command menus. You can also refer to
the help message as necessary for information about each command, which
appears on the operation monitor by pressing the [F1] key.
Command menu windows selectable from MANUAL mode
47501-D8-00
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY B/SERVO_CONTROL
A1 INPUT/OUTPUT MONITOR
A2 FEEDER OUT MONITOR
A3
A4 VACUUM IN MONITOR
A5 CHANGE NOZZLE
A6 ATS/YTF/ PALETTE
A0 CONVEYOR UNITS
B1 SELECT SERVO MOTOR [AXIS]
B2 RUNNING SPEED [SPEED]
B3 POINT MOVE
B4
B5
B6 INIT. SERVO ORIGIN
B0 EXIT FROM MANUAL
Reference
This MANUAL mode of MAINTENANCE Manager is exactly the same as MANUAL mode
of the OPERATION and DATA Managers.
Since an optional tray changer (YTF80W, ATS20) cannot be connected to the YV180X, the
<A6 ATS/YTF PALLET> command is invalid.
