5 -7 SED8013110 Service Manual Chapter 5 5 Manual mode 2.4 Change nozzle <3/4/A5> Use the <3/4/A5 NOZZLE CHANGE> command to change the nozzle of a particular head. This command is enabled only for heads with …
5
-6
Service Manual
Chapter 5
SED8013110
5
Manual mode
2.2 Feeder out monitor
<3/4/A2>
When <3/4/A2 FEEDER OUT MONITOR> is selected, the FEEDER
OPERATION screen appears as shown below. Pressing the [ENTER] key
turns the air valve operation on and off for the feeder on which the cursor
is placed.
FEEDER OPERATION screen
47505-D8-00
< FEEDER OPERATION >
1 - 8
9 - 16
17 - 24
25 - 32
33 - 40
41 - 48
49 - 56
57 - 64
00000000
00000000
00000000
00000000
00000000
/ / / / / / / /
/ / / / / / / /
/ / / / / / / /
101 - 108
109 - 116
117 - 124
125 - 132
133 - 140
141 - 148
149 - 156
157 - 164
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY
00000000
00000000
00000000
00000000
00000000
/ / / / / / / /
/ / / / / / / /
/ / / / / / / /
2.3 Vacuum IN monitor
<3/4/A4>
When <3/4/A4 VACUUM IN MONITOR> is selected, the VACUUM
SENSOR LEVEL screen appears as shown below. Pressing the [ENTER]
key allows you to monitor the vacuum operation of the head on which the
cursor is placed.
VACUUM SENSOR LEVEL screen
47506-C0-A0
[ ↑ ] [ ↓ ] : Select Head [Enter]:Vaccum ON/OFF
VACCUM SENSOR LEVEL
CURRENT
0
0
0
0
0
0
0
0
MAXINMUM
0
0
0
0
0
0
0
0
MINIMUM
0
0
0
0
0
0
0
0
HEAD
A
A
A
A
A
A
A
A
From MachineOrigin X1= Y1= Z1= R1=
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY
[Esc]:Exit
[Space]:Freeze Display
5
-7
SED8013110
Service Manual
Chapter 5
5
Manual mode
2.4 Change nozzle
<3/4/A5>
Use the <3/4/A5 NOZZLE CHANGE> command to change the nozzle of a
particular head. This command is enabled only for heads with an FNC
(flying nozzle change) function (Heads 2, 4, 6, 8).
CHANGE NOZZLE command
47507-D8-00
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY B/SERVO_CONTROL
A5 CHANGE NOZZLE
SELECT NOZZLE
Type 71
Type 72
Type 73
Type 74
Type 75
Type 76
Type 77
Head Selection
Head 1
Head 2
Head 3
Head 4
Head 5
Head 6
Head 7
Head 8
Table Selection
A table
B table
Reference
This command is the same as the <3/3/A5 CHANGE NOZZLE> command in
MACH_ADJUST mode.
2.5 Conveyor units
<3/4/A0>
This command allows you to turn on and off the conveyor units for clamp-
ing a PCB in the component mounting position.
CONVEYOR UNITS menu box
47508-D8-00
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
LOCATE PIN
PUSH UP
PCB CLAMP
EDGE CLAMP
PUSH IN
MAIN STOPPER
ENT.STOPPER
EXIT STOPPER
CONV. MOTOR
CONV. WIDTH
PROGRAM PIN
RETURN
CONVEYOR UNIT (STS.)
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY B/SERVO_CONTROL
A0 CONVEYOR UNITS
Reference
This command opens the same CONVEYOR UNITS menu box that appears when you run
the <1/1/D4 ASSISTANT UTILITY> command in OPERATION Manager or the <2/1/B7
CONVEYOR UNITS> command in DATA Manger. For details on this menu, see the
mounter operation manual.
5
-8
Service Manual
Chapter 5
SED8013110
5
Manual mode
3. Servo control
<3/4/B>
On the <3/4/B SERVO_CONTROL> menu, you can use commands for
axis movement during MANUAL mode. To run a command, move the
cursor to the command and press the [ENTER] key or directly enter the
corresponding number. The function of each command is explained below.
3.1 Select servo motor
<3/4/B1>
When you run <3/4/B1 SELECT SERVO MOTOR>, the submenu box
appears for selecting the axis, so move the cursor to the axis you want to
move and press the [ENTER] key.
Axis selection box
47509-C0-00
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY B/SERVO_CONTROL
B1 SELECT SERVO MOTOR [AXIS]
A_Table XY
A_Table ZR
B_Table XY
B_Table ZR
A_Table Width
B_Table Width
Transfer PCB
3.2 Running speed
<3/4/B2>
When you run <3/4/B2 RUNNING SPEED>, the submenu box appears for
selecting the axis movement speed, so move the cursor to the desired speed
and press the [ENTER] key. You can also change the speed settings (per-
centage) with the number keys.
Speed selection box
47510-C0-00
Speed1 =
Speed2 =
Speed3 =
Speed4 =
Speed5 =
Edit speed.
From 1 to 100
Cursor key : Select
Ok[Enter],Abort[ESC]
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 4/MANUAL
<COMMAND_LIST> A/IO_UTILITY B/SERVO_CONTROL
B2 RUNNING SPEED [SPEED]
100
80
60
40
20
