Chapter 3 Machine data edit mode 1. Machine data edit mode main menu 3-3 2. Head 3-4 2.1 V acuum level ............................................................................................. 3-5 2.2 Offset ........…
2
-19
SED8013110
Service Manual
Chapter 2
2
Machine configuration mode
2.10.2 Feeder spec type information
The feeder spec type information shows the air drive timers for each feeder.
Feeder spec type information
47216-C0-00
FeederType
8mmTape
8mm1005cmp
12mmEmboss
12mmLongPitch
16mmEmboss
24mmEmboss
32mmSticky
32mmEmboss
44mmEmboss
56mmEmboss
MultiStick
WideMultiStick
Fix. TF
Ext. TC
AutoTC
Tape-A
Tape-B
PNEUMATIC Type
Load
0
20
15
25
25
25
30
40
40
40
100
100
0
0
0
0
0
Min.
0
0
0
5
5
5
10
20
20
20
0
0
0
0
0
0
0
Down
0
6
5
0
0
0
0
0
0
0
2
2
0
0
0
0
0
Timar
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 1/MCH_CONFIG
Load Time necessary to load components continuously
from the same feeder (in hundredths of a second)
Min. Minimum time required for a tape feed (in hun-
dredths of a second)
For bulk feeders, this setting indicates the air blow
time necessary for proper feed of components.
Down Time delay when the head assembly begins to move
down after the feeder shutter has opened (in
hundredths of a second).
Chapter 3
Machine data edit mode
1. Machine data edit mode main menu 3-3
2. Head 3-4
2.1 Vacuum level .............................................................................................3-5
2.2 Offset .........................................................................................................3-6
2.3 Down offset ...............................................................................................3-7
2.4 Nozzle correction ......................................................................................3-8
2.5 R axis accuracy ..........................................................................................3-9
3. Camera 3-10
3.1 Coordinate/spec .......................................................................................3-10
3.2 Vision parameter ......................................................................................3-11
4. Machine 3-12
4.1 Feeder plate offset ....................................................................................3-13
4.2 Software limits .........................................................................................3-18
4.3 Position ....................................................................................................3-19
5. Other 3-20
5.1 RS-232C...................................................................................................3-20
6. Precision 3-21
6.1 MultiCam Marker .....................................................................................3-21
This chapter describes MCH_DATA (machine data edit) mode,
including how to read the data edit screens and what each parameter
means.
3
-3
Service Manual
3
Machine data edit mode
Chapter 3
SED8013110
1. Machine data edit mode main menu
In Machine Data Edit (MCH_DATA) mode, you can check various ma-
chine data items for the mounter and related options.
When you select <3/2/ MCH_DATA> and press the [ENTER] key, the
MCH DATA SORT menu box appears. Selecting an item from this menu
box further displays the submenu box, so select the parameter item you
want to check and press the [ENTER] key. The current machine data
settings for the selected item are then displayed.
Main menu box in the Machine Data Edit mode
47301-C0-00
MCHDATA SORT
Head
Camera
Machine
Tray Changer
Station
Other
Precision
Spare Data
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 2/MCH_DATA
c
CAUTION
The parameters in MCH_DATA mode are properly set at the factory prior to shipment,
according to the required specifications. Do not change these parameter settings. If an
adjustment becomes necessary, use the adjustment command or edit screen in
MCH_ADJUST mode explained in Chapter 4.
Reference
The YV180X cannot be connected to an optional tray changer and nozzle station, so “Tray
Changer” and “Station” on the menu are disabled.
