2.2 Offset

Selecting “Offset” from the “Head” submenu opens the Head Offset screen

showing the positional offset of each head relative to Head 1.

Head Offset screen

47304-D8-00

Head No.

Head 1 A

Head 2 A

Head 3 A

Head 4 A

Head 5 A

Head 6 A

Head 7 A

Head 8 A

HeadType

Manual NzlChg

AutoNzlChg

Manual NzlChg

AutoNzlChg

Manual NzlChg

AutoNzlChg

Manual NzlChg

AutoNzlChg

0.000

15.992

32.020

48.004

64.008

79.996

96.033

112.030

0.000

0.008

0.026

-0.028

0.018

0.003

-0.002

0.000

-0.010

0.010

-0.020

-0.010

-0.030

0.010

-0.050

Nozzle

TYPE-72

OBJECT

Head Offset

TCH. UNIT SPEED

- - - - - - - -

<<<APPLICATION>>> 3/MAINTE/M

<<MODE>> 2/MCH_DATA

HeadType Set to “AntoNzlChg” for FNC heads (Heads 2, 4, 6,

8) and to “ManualNzlChg” for the other heads

(Heads 1, 3, 5, 7).

X, Y, Z Shows the positional offset (mm) of each head

relative to Head 1. Head 1 is always “0.000”.

Nozzle Specifies the nozzle type attached to each head.

This parameter is enabled only when “HeadType” is

set to “Fixed Nozzle” or “DispenseNzl”.

NOTE

Head offset XYZ can be automatically adjusted by running the AMF (auto mount

feedback) utility. See the AMF manual for details.

-7

Service Manual

Machine data edit mode

Chapter 3

SED8013110

2.3 Down offset

Selecting “Down Offset” from the “Head” submenu opens the Head Down

Offset screen as shown below. Data entered here are offset settings for

correcting a positional shift of the rotational center of each head which

occurs when it descends to pick up a component, lighting method, etc.

Head Down Offset screen

47305-D8-00

<<<APPLICATION>>> 3/MAINTE/M

<<MODE>> 2/MCH_DATA

Head No.

Head 1 A

Head 2 A

Head 3 A

Head 4 A

Head 5 A

Head 6 A

Head 7 A

Head 8 A

OBJECT

Vacuum Level

TCH.UNIT SPEED

- - - - - - - -

0.000

X correct

0.000

Y correct

0.000

HeadType

Fore

FIneMode

impossible

X, Y Shows XY offset (mm) of the rotational center of

each head when it descends to pick up a compo-

nent. This parameter affects the component pickup

action only, and does not affect the mounting

accuracy.

X, Y correct Shows XY offset to correct a mounting position shift

caused by a component which is not perpendicular

to the PCB surface when picked up by a nozzle. Set

this parameter to “0.000” in most cases.

HeadType Shows the lighting method that matches each head.

All heads of the YV180X should be set to “Fore”.

FineMode This function cannot be used with the YV180X and

should be set to “impossible”.

NOTE

Head down offset can be automatically adjusted by running the AMF (auto mount

feedback) utility. See the separate AMF manual for details.

-8

Service Manual

Chapter 3

Machine data edit mode

SED8013110

2.4 Nozzle correction

Selecting “NozzleCorrection” from the “Head” submenu opens the Nozzle

Correction screen as shown below. Data entered here are offset settings

(mm) for correcting a positional shift of the center of each head. These

positional shifts for example occur if the nozzle shaft is bent an amount

equal to the difference between recognition height and mounting height

even though nozzle angle remains the same.

Nozzle Correction screen

47306-D8-00

<<<APPLICATION>>> 3/MAINTE/M

<<MODE>> 2/MCH_DATA

Head No.

Head 1 A

Head 2 A

Head 3 A

Head 4 A

Head 5 A

Head 6 A

Head 7 A

Head 8 A

OBJECT

NozzleCorrection

TCH.UNIT SPEED

- - - - - - - -

0.000

NOTE

Nozzle correction can be automatically adjusted by running the AMF (auto mount

feedback) utility. See the separate AMF manual for details.
