Camera lens
Check for dirt and grime on the camera lens, half-mirror and lighting unit.
To clean, use a cleaning stick supplied with the machine or similar cotton
swab, slightly moistened with alcohol, and gently wipe the surface of the
lens or mirror. If component chips or debris are on the lens or half-mirror,
remove them.
c
CAUTION
Do not apply excessive force to the camera as this may adversely affect the optical axis,
making the vision parameter settings unreliable.
Feeder
Check that all feeders are securely set on the feeder plate. For daily
inspection of feeders, see the FEEDER user’s manual.
Feeder plate
Check that no chips, debris and solder are on the feeder plate. Clean the
feeder place if necessary.
1
-8
Service Manual
Chapter 1
SED8013110
1
Inspection and maintenance
2.2 Periodic inspection
In addition to daily inspections, periodic inspections (weekly, monthly and
every 6 months) are essential to ensure safe and efficient use of the ma-
chine. We recommend setting an earlier inspection interval if parts are
subject to frequent usage. For detailed information on inspection methods,
refer to the separate Maintenance Guide (Basic).
2.2.1 Weekly inspection
Weekly checkpoints
45101-D8-00
Air supply unit
Moving
camera
Multi-view
camera
X, Y, W axes
Feeder plate
Nozzle and
peripherals
Mist filter
Air filter
Lighting uni
Lens
Half-mirror
Lighting unitt
Ball screw
Linear guide
Air valve
Air joint
Nozzle
Leaf spring
(Heads 1, 3,
5, 7)
Nozzle holder
FNC (Heads
2, 4, 6, 8)
2.1 in
Chapter 1
2.1 in
Chapter 1
2.1 in
Chapter 1
Check for oil and water deposits in the filter cup.
Drain if found.
Check for dust or impurities trapped by the air filter.
If found, use an air gun to blow them away.
Check for dust and grime on the lighting unit and
lens tube. Clean if necessary.
Check to see if each LED illuminates sufficiently. I
not, replace the whole LED unit.
Check for dust and grime on the lens, half-mirror
and lighting unit. Clean if necessary.
Check for chips and debris on the camera unit.
Remove if found.
Check for chips and debris on the ball screw.
Remove if found.
Check for hardened grease, chips and debris on
the linear guide. Remove if found.
Check that the air valves work normally.
Check for air leak by wear of the O-ring or Y-
packing. Replace if necessary.
Check for wear or damage to the nozzle tip, and for
any solder adhering. Replace or clean if necessary.
Check for the spring-action movement. Clean if
not smooth.
Check that the leaf springs are correctly attached.
Replace if deformed or fatigued.
If the leaf spring screw is loosened, retighten it.
Check for the spring-action movement. Lightly
apply lubricant if movement is not smooth.
If the holder screw is loosened, retighten it.
Check for chips and debris adhering to the gear parts
or positioning pin holes. Remove if found.
Checkpoints Check items Notes
ESD8_CH3(01-09)
1
-9
SED8013110
Service Manual
Chapter 1
1
Inspection and maintenance
2.2.2 Monthly inspection
Monthly checkpoints
45102-D8-00
Check for damage, wear and tension.
Adjust the tension or replace the belt if
necessary.
Check the actuation timing. Adjust the
speed if necessary.
Check that each sensor works correctly.
Remove dust and debris, and apply a thin
coat of grease by hand.
Remove dust and debris, and apply a thin
coat of grease by hand.
Check for damage, wear and tension.
Adjust the tension or replace the belt if
necessary.
Check for bend or deform of the hook.
Replace if found.
Check for damage, wear and tension.
Adjust the tension or replace the belt if
necessary.
Check for excessive slack and damage.
Adjust or replace if necessary.
Check for looseness and damage.
Connect securely or replace if necessary.
Checkpoints Check items Notes
Conveyor
X, Y, Z, W axes
W axis
T axis
R axis
Wire harness
Conveyor belt
Conveyor units
Ball screw
Linear guide
Ball screw
Linear guide
PCB transfer belt
Timing belt
Spline belt
Transfer hook
Wire harness
Connector
1.3 in
Chapter 6
1.1 in
Chapter 6
2.2.3 6-month inspection
6-month checkpoints
45103-D8-00
Remove dust or debris with an air gun.
Replace the filter if exceedingly dirty.
Check for clog in the air path of the spline
shaft. Clean if clogged.
Check for damage, wear and tension.
Adjust the tension or replace the belt if
necessary.
Clean the FD drive using a commercially
available head-cleaning disk.
Checkpoints Check items Notes
Ejector
(Vacuum
generator)
Spline shaft
W axis
Other
Air filter
Air path
Timing belt
FD drive
