2 -16 Service Manual Chapter 2 SED8013110 2 Machine configuration mode 2.9.2 Nozzle spec type information The nozzle spec type information shows component types that can be picked up by each nozzle. Digit “ 0 ” means the…
2
-15
SED8013110
Service Manual
Chapter 2
2
Machine configuration mode
2.9 Nozzle spec information
<3/1/B3>
When <3/1/B3 NOZZLE SPEC INF.> is selected, the submenu box
appears for selecting “NOZZLE SPEC CMN. (nozzle spec common)
information” and “NOZZLE SPEC TYP. (nozzle spec type) information”.
Each item on this submenu is explained below.
Nozzle spec information submenu
47211-C0-00
B1 HEAD SPEC. INF.
B2 FEEDER PLATE SPEC INF.
B3 NOZZLE SPEC INF.
B4 FEEDER SPEC INF.
B5
B6 DISPENSE SEQ. INF.
B7 DISPENSE COR. INF.
B0 EXIT
NOZZLE SPEC
NOZZLE SPEC CMN.
NOZZLE SPEC TYP.
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 1/MCH_CONFIG
<COMMAND_LIST> B/SPEC_INF
2.9.1 Nozzle spec common information
The nozzle spec common information shows specifications of nozzles used
with this machine.
Nozzle spec common information
47212-C0-00
Nozzle
TYPE- 71
TYPE- 72
TYPE- 73
TYPE- 74
TYPE- 75
TYPE- 76
TYPE- 77
TYPE- 78
TYPE- 79
TYPE- 7A
TYPE- 7B
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 1/MCH_CONFIG
H. mm
0.00
0.00
0.00
-1.00
0.00
0.00
0.00
0.00
0.00
0.00
0.00
Num
100
100
100
100
100
100
100
100
100
100
100
Dia
13
20
30
80
0
30
0
0
0
0
0
H mm Difference in nozzle length in relation to reference
nozzle
Num The number of nozzles used with this machine
Dia. Nozzle tip diameter (in tenths of a millimeter)
2
-16
Service Manual
Chapter 2
SED8013110
2
Machine configuration mode
2.9.2 Nozzle spec type information
The nozzle spec type information shows component types that can be
picked up by each nozzle. Digit “0” means the component can be picked up
and code “-” means it cannot be picked up.
Nozzle spec type information
47213-C0-00
For1005Chp71
Component
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 1/MCH_CONFIG
1234
0----------------------------------------------------------
-000---00----0---------------------------------------------
----000---00--00-----0-------------------------------------
------------0---000---00-----------------------------------
-----------------------------------------------------------
---------0-------------------------------------------------
-----------------------------------------------------------
-----------------------------------------------------------
-----------------------------------------------------------
-----------------------------------------------------------
-----------------------------------------------------------
Buffing
Use
Use
Use
NotUse
NotUse
NotUse
NotUse
NotUse
NotUse
NotUse
NotUse
Nozzle
TYPE- 71
TYPE- 72
TYPE- 73
TYPE- 74
TYPE- 75
TYPE- 76
TYPE- 77
TYPE- 78
TYPE- 79
TYPE- 7A
TYPE- 7B
5
Component Component types are horizontally listed in order.
The name of the component being selected appears
on the top line, together with the nozzle type.
“0”: can be picked up, “-”: cannot be picked up
Add Blow Specifies whether to perform air blow to prevent the
nozzle from taking a component back without
mounting it.
Buffing Specifies whether the nozzle uses spring action or
not.
c
CAUTION
Do not specify two or more nozzle types as “0” for the same component. Otherwise, the
machine may not operate correctly.
YAMAHA standard nozzles for the YV180X are specified as Type 71 to Type 79. If a
custom nozzle is used, it should be specified from Type 7A to Type 7Q, and the name
“Sp. NozzleA” to “Sp. NozzleF“ , which is the “component/nozzle” name shown on the
top line, should be specified in the component information.
2
-17
SED8013110
Service Manual
Chapter 2
2
Machine configuration mode
2.10 Feeder spec information
<3/1/B3>
When <3/1/B4 FEEDER SPEC INF.> is selected, the submenu box appears
for selecting “FEEDER SPEC CMN. (feeder spec common) information”
and “FEEDER SPEC TYP. (feeder spec type) information”. Each item on
this submenu is explained below.
Feeder spec information submenu
47214-C0-00
B1 HEAD SPEC. INF.
B2 FEEDER PLATE SPEC INF.
B3 NOZZLE SPEC INF.
B4 FEEDER SPEC INF.
B5
B6 DISPENSE SEQ. INF.
B7 DISPENSE COR. INF.
B0 EXIT
FEEDER SPEC
FEEDER SPEC CMN.
FEEDER SPEC TYP.
<<<APPLICATION>>> 3/MAINTE/M
<<MODE>> 1/MCH_CONFIG
<COMMAND_LIST> B/SPEC_INF
