6-1 6 Managing the data 1. Data backup Production board data and system data can be backed up. This section explains how to make a backup of these data. 1.1 Making a backup of board data A backup cop y of board data can …

Chapter 6 Managing the data

This chapter explains how to back up board data and make a user database, as well as how to view and save the production

and machine operation logs.

Contents

1. Data backup 6-1

1.1 Making a backup of board data 6-1

1.1.1 Backing up onto a USB flash drive 6-2

1.2 Making a backup of system data 6-6

1.2.1 System backup settings 6-7

1.2.2 Making a backup 6-8

1.3 Restoring the system data 6-11

1.3.1 Restoring a system backup 6-11

1.3.2 Restoring a system full backup 6-13

2. Creating the user database 6-16

2.1 Copying the data into the database 6-16

3. Production log management 6-18

3.1 Production log types 6-18

3.1.1 Production log (MIS) 6-18

3.1.2 Operation log (Unit Log) 6-20

3.1.3 Other operations 6-22

3.2 Production and operation log settings 6-24

3.2.1 Specifying the auto-save destination 6-24

3.2.2 History Utility 6-27

6-1

Managing the data

1. Data backup

Production board data and system data can be backed up. This section explains how to make a backup of

these data.

1.1 Making a backup of board data

A backup copy of board data can be stored on a USB flash drive or on a network drive (including on-line

software). When board data is saved in YGZ format, it can be stored in any location. However, when using a

USB flash drive, the data should be stored in a predetermined location.

CAUTION

Use a USB ﬂash drive (supplied with the machine or purchased from YAMAHA sales reps) speciﬁed by YAMAHA Motors

Co., Ltd. U sing a USB ﬂash drive other than speciﬁed might cause problems. Do not use any other type of USB ﬂash

drive with YAMAHA surface mounters and related machines.

CAUTION

Before operating the USB ﬂash drive to copy data, always close the media access door to prevent dust from adhering

to the USB port and to protect the USB ﬂash drive from electrostatic noise.

CAUTION

After copying board data or system data into a USB ﬂash drive, do not leave that data in the USB ﬂash drive for a long

time. Use the USB ﬂash drive just as a copy medium for backup data. Prepare other backup media (CD , DVD , MO ,

etc.) to store the backup data.

6-2

Managing the data

1.1.1 Backing up onto a USB flash drive

Follow the steps below to backup data to a USB flash drive using the Board Explorer.

When using a USB flash drive, you need to create a "board" folder to make a directory (folder) named "No1".

Backup data should be stored there.

TIP

You may use the [Save] button to save board data to a USB ﬂash drive.

Insert a USB flash drive into the USB port.

Insert a specified USB flash drive into the USB port of the machine.

The USB port can be seen when opening the panel door at the lower portion of the front of this

machine.

USB port

63601-N1-00

Close the media access door.

Before operating the USB flash drive, always close the media access door.

Check the USB flash drive connection.

Check the indicator on the lower left of the operation display.

The connection is complete when the USB flash drive icon appears red.

The connection is incomplete if the USB flash drive icon is grayed out.

Checking the USB flash drive connection

Not connectedConnected

Icon appears "red". Icon is grayed out.

64601-N1-10

Press the [Board Explorer] button on the [Utility] tab of the Setup screen.

The Board Explorer screen appears and shows the lists of board data stored in the machine. (The

right-hand and left-hand lists will show the same contents when the Board Explorer first opens.)
