6-13 6 Managing the data 1.3.2 Restoring a system full backup T o restore the system full backup data, use the dedicated software installed on a PC. T he following steps describe how to restore system data into a flash d…

100%1 / 288
6-12
6
Managing the data
3. A confirmation screen appears to restore the backup data. Press the [Yes] button to start restoring
the system data.
4. When the system data has been restored, a "Restore Completed" screen appears. Press the [OK]
button to close the screen.
Restoring the system data
64616-N1-00
5. When returned to the "System backup" screen, press the [Close] button to exit it.
Restoring the system backup data is now complete.
6-13
6
Managing the data
1.3.2 Restoring a system full backup
To restore the system full backup data, use the dedicated software installed on a PC.
The following steps describe how to restore system data into a flash disk using the system full backup data
stored in a USB flash drive.
n
Required components and devices
• Flash disk (parts No. and name: KHL-M4255-00 FLASH DISK)
• Data acquired by system full backup
• PC (Windows XP or later)
• Card reader or memory card adapter
c
CAUTION
Always use a YAMAHA genuine flash disk. U sing other flash disks may cause malfunction.
n
NOTE
Use a PC with any of the following OS: Windows XP Professional (32 bits) / Windows Vista (32 bits) / Windows 7 (32 bits /
64 bits)
n
Restoring onto a flash disk
1
Connect the USB flash drive to the PC.
1. Insert the USB flash drive containing the system full backup data into the USB port of the PC.
2. A screen appears asking you to select what you want Windows to do. Select “Using Windows
Explorer to open a folder to display a file” and click the [OK] button. The “REMOVABLE” screen then
appears.
TIP
If the data acquired by system full backup is stored on the network, select the folder containing the system full backup
data you want to restore.
2
Start the restore software.
1. Double-click the folder that was created by system full backup.
2. The folder contains three files. Double-click the “VgosSystemFullBackup.exe” file, and the restore
software starts up.
Starting the restore software
Double-click this file.
64617-N1-00
6-14
6
Managing the data
3
Restore the system data.
When the “VgosSystemFullBackup” screen appears, check that the backup data is for the machine
where you want to restore and click the [Next] button. The “FLASH DISK” screen then appears.
c
CAUTION
If a flash disk is connected to the PC , remove it and then click the [Next] button.
Checking the machine
Check here.
64618-N1-00
4
Connect the flash disk.
When the flash disk is connected to the PC, it is detected by the PC and displayed in the screen.
The [Next] button becomes active, and click it to continue.
When flash disk is connected
Detected flash disk
64619-N1-00
c
CAUTION
• Windows Explorer may automatically start when a flash disk is connected to the PC.
If any application automatically starts, quit it.
• If the flash disk is not detected even after connecting it to the PC , remove the flash disk and then reconnect it again.
• Restoring will write the system full backup data over the data in the flash disk.
