2-10
2
Basic operations
3
Press the [Operator] button on the operation screen.
The "ID WINDOW" appears for specifying the machine operator.
[Operator] button
[Operator] button
64203-N1-10
4
Specify the operator and enter the password.
You may select "Administrators" or "Operators" from the GROUP NAME dropdown list as needed.
If the password is correct, the initial screen (Setup screen before selecting a board) appears on the
screen.
Specifying the operator
Select operator and press [OK].
64204-N1-00
TIP
For information on how to select board data or how to operate the machine, see "Chapter 4 Daily operation", after
making sure that you understand the contents of this chapter.
TIP
Active menu buttons differ depending on the operation level setup. For example, when the machine is powered on
with the factory setup, the program starts up at an operation level called "Default Operator". This "Default Operator"
level is set to "Level 0" at the time of shipment to allow only basic operation items. This operation level can be
changed as needed. Operators and operation items can also be added and specified by setting the password and
operation level.
2-11
2
Basic operations
2.3 Powering off the machine
To power off the machine, follow these steps.
1
Press the [Off] button on the operation screen.
[Off] button
[Off] button
64205-N1-10
2
Press [Yes] button when the "SHUT DOWN" screen appears.
"SHUT DOWN" screen
64206-N1-00
3
Press the [OK] button when the "Move-to-origin" screen appears.
All axes move back to their origins.
2-12
2
Basic operations
4
Press [Yes] button when the "SHUT DOWN" screen appears.
The application software automatically closes.
e
5
Press the emergency stop button.
When the "emergency stop" screen appears, press the emergency stop button and then press the [OK]
button.
6
Turn off the machine power switch.
When the message to power off the machine, "It is now safe to turn off your computer" appears, turn
counterclockwise the power switch on the machine to power off the machine.
c
CAUTION
Data or machine might be damaged or lost if powering off the machine without following the above sequence.
c
CAUTION
To start the machine again after powering off the machine, wait for 2 sec. or longer and power on the machine. If you
ignore this instruction, a trouble may occur when starting the machine again.
