NPM-W2 EJM7DE-MB-07O-00
7-1-1-7
No. Item name Function when [ON] is selected
1 Feeder maint warning
Displays a warning message when the shot count of tape feeder has
exceeded the warning value.
2
Part remainder number
warning
Displays a warning message when “Feeder remainder number warning
length” in “Action parameters” is reached.
3
Simple Remain
Manage
When the remainder of a reel used reaches 1, this option resets the
remainder, assuming that the reel has been used up.
4
Supply parts count
input when running
Allows the supply parts count for splicing to be input without stopping
production.
5 Splicing length stop
Causes the machine a single stop when the remaining reel is less than 1
200 mm (minimum length required for splicing).
6
Fdr parts collation
(option)
If tape feeders containing any parts different from those in the production
data downloaded to the machine are loaded, the interlock function of the
machine is activated, causing the machine to stop due to an error.
7
Unconditional parts
splicing
Enable parts to be re-verified when feeder parts verification is ON, even
though splicing verification has already been done.
8
Component splicing
executes when
remaining warning
happen
Enables splicing only for tape feeders with which a remainder warning has
occurred.
9 Feeder deploy free
Allows a tape feeder containing the same parts can be placed at any
desired slot before starting production or if parts empty has occurred. When
the specified feeder is used up, the arranged feeder is used automatically to
continue production.
10
Pick up sequence has
high priority when free
arrange
Gives priority to simultaneous pickup if it is involved when picking up parts
with “Feeder deploy free” ON. Notifies the operator that the cycle time may
be slower depending on the tape feeder arrangement.
Setting information 6
● Default ：OFF
■ Feeder
Unit
setting
Option setting 4
Operating procedure
7-1-1
NPM-W2 EJM7DE-MB-07O-00
7-1-1-8
No. Item name Function when [ON] is selected
11
Fdr parts collation
(Time of feeder set )
If tape feeders have been removed/set during single stop, this option
executes parts collation for the feeders concerned after production is started.
If there is no problem, production continues. If any problem is found, a
message “Hasn’t executed parts verification” appears and the machine stops.
12
Feeder outside parts
collation
Enables tape feeder collation by the customer’s parts collation system.
When replenishing parts after a parts empty error, this option inquires of the
parts collation system whether collation has done. If collated, parts
replenishment will be completed to continue production. If not collated, parts
replenishment is considered to be unfinished and production will be stopped.
13
Substituted parts auto
change
Enables pickup of substitute parts using the registered data when the master
parts are used up.
14
All arranged
components supply
target
Allows loading of tape feeders that contain any parts registered in the
arrangement list.
15
Auto Cart Height
Measure
When several feeder carts are used for one machine, pickup rate lowers due
to variation in the height of cart. To prevent this problem, this option
measures the height of reference post automatically to make correction.
16 Stop at S-tape sense
Causes the machine a single stop if the splicing tape is detected, and
displays an error message “Splicing tape detection stop”.
17
Material empty check
of trans table
(Currently unused)
Detects material empty of the transfer tables (supply tables A to D) by the
sensor mounted on the transfer unit.
18
Trans material empty
check of syringe
(front)
(Currently unused)
Detects material empty of the syringe (supply tables A to D) by the sensor
mounted on the transfer unit.
19
Trans material empty
check of syringe(rear)
(Currently unused)
Detects material empty of the syringe (supply tables A to D) by the sensor
mounted on the transfer unit.
20
Syringe trans material
empty stop
(Currently unused)
Syringe trans material empty stop
Setting information 7
● Default ：OFF
■ Feeder
System
administration
NPM-W2 EJM7DE-MB-07O-00
7-1-1-9
No. Item name Function when [ON] is selected
21
Feeder mark
recognition
Recognizes the mark at the retainer of the feeder tape, to perform pickup
position teaching automatically.
Pickup position teaching is not required for transparent embossed tape and
12 mm or wider feeder parts.
22
Disused Feeder LED
ON at Auto Prod Start
Turns ON the green LED of the tape feeders that are not used for production
at the start of operation.
23
Certify Feeder First
Pick Up Pos Teach
after Change over
Displays the screen that shows the feeder pickup position after production
changeover. Confirm the pickup position before the first pickup.
24
Confirm stock parts
verification again
Displays a window for confirming the target parts when parts with stock have
been collated.
25
8mm feeder(paper)
gap correct function
If a recognition error has occurred with a part that requires pocket recognition
at the start of recognition, the tape is fed by a half pitch automatically. If the
part is present, correction is made after the pocket is recognized again.
26
Pick up position teach
Parts shape display
Displays a frame showing the shape of part on the Pickup position teach
screen (Arrange - PartsPrepare - Feeder - Pickup pos) and Pickup position
check error screen.
27
Prevention of feeder
over-exposure
Changes the input range for the second origin offset according to the size of
the flat chip (to prevent values beyond the half of the part size from being set
as the second origin offset).
28
Thin Type Single
Feeder
Allows the thin type single feeders to be used.
29
Pickup position teach
before the production
start
Causes all machines to perform pickup position teaching before starting
production.
30
Display pickup
position teach
when occurred feeder
error
Moves the head to the pickup position of the tape feeder if the machine
comes to a single stop due to any of the following feeder errors.
Setting information 8
● Default ：OFF
■ Feeder
Unit
setting
Option setting 5
Operating procedure
7-1-1
