NPM-W2 EJM7DE-MB-07O-00
31
1
3
7-3-3-2
■To change the offset display area using a matrix
2
4
5
B
3
2
5
Touch the display area
(Matrix moves right or left)
(Offset of the area selected in is
displayed in )
■When you do not select the area to
display the offset
Choose an area to display the
offset
■When you do not clear plane
correction parameters
Confirm the message
System
administration
NPM-W2 EJM7DE-MB-07O-00
7-3-4-1
Machine
parame-
ter
Head origin offset
check
You can check the origin offset values (calibration result) of θ-/Z-axes.
A
B
B
A
Operating procedure
7-3-4
θ [°]
Offset angle on head origin.
Z [mm]
Offset of the height direction of Z-axis
of each loading head.
Placement head
A
B
B
A
θ [°]
Offset angle on head origin.
Z [mm]
Offset of the height direction of Z-axis
of each dispensing head.
Dispensing head
NPM-W2 EJM7DE-MB-07O-00
7-3-4-2
System
administration
