SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition
111
12.3.2 OIS Database Settings
Configure the OIS database connection accordingly.
Figure 12-5 FM Line Console OIS Database Connection Configuration
Note:
Unlike previous versions, the OIS Database connection shall be configured in FM Line
Console Server Configuration, instead of being done during the installation process.
Only when the correct OIS Database setting is configured can FM Line Console collect
the feeder cycle count information.
12.3.3 Server Settings
Figure 12-6 FM Line Console Server Configuration: FM Server
Enter the appropriate name for FM Server and OIB Core.
SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition
112
Note:
If the OIB Core address is changed, you will be prompted to restart the FM Line Console
Server.
After restarting, all the lines and stations previously configured will be removed from FM
Line Console. And you must reconfigure the production lines and stations.
12.4 Show Status
The working status of FM Line Console can be seen from the system tray icon, and the details
is available from the Show Status option. When Show Status is clicked, following status
window will be shown.
Figure 12-7 FM Line Console Server Status
12.5 Online Help
User can access the Online Help for FM Line Console either via the ASM Studio main menu
or by press the F1 button. See chapter 10 Help for more details.
SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition
113
12.6 Icons used in FM Line Console
FM Line Console uses the same icons as FM Client and additionally the following ones:
Icon
Description
Location
Production Line / Offline Area
Line with a feeder problem
Station with a feeder problem
Station Location with a feeder problem
Feeder
Feeder maintenance is Normal
Feeder maintenance status is Due/Overdue (unforced),
or the feeder mismatches the target setup
Feeder status is Scrapped or Blocked
Table 12-3: Icons in FM Line Console
