SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition

Figure 5-20 Feeder Barcode Printer Selection

Note:

Feeder Manager default printer is independent of the Windows default printer setting.

See section 9.4 Print Options for details.

For subsequent printings, following message will be shown

Figure 5-21 Feeder Barcode Default Printer Confirmation

 Click Yes to directly print to the default printer.

 Click No to open the printer selection dialog.

Export Service and Exchange History to Excel

 Click on this button to export the service and exchange history of all the feeders shown in

the result list to an excel file.

Export Result to Excel

 Use this button to export the search result into Excel format.

SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition

Note:

Exported excel files require Excel Viewer 2007 or higher to open.

5.4 Feeder Maintenance Workflow

Note: starting from Feeder Manager 3.0, the feeder maintenance and repair workflow will be

followed in a guided way to avoid unwanted input errors.

The Feeder Maintenance Workflow can be accessed via two places

1) Via the main meu. Go to Feeder  Feeder Maintenance Workflow

Figure 5-22 Access Feeder Maintenance Workflow from the main menu

Note: You will need to key in or scan the feeder ID to be maintained.

2) Via the Action button of Feeder details.

Open up a certain Feeder’s feeder detail view, and then press the Action button to bring

up the dropdown list of actions. Select Feeder Maintenance Workflow

Figure 5-23 Access Feeder Maintenance Workflow from the feeder detail view

Note: in this approach, the Feeder ID of the feeder selected will be pre-entered into the

first page of the Maintenance Workflow.

The feeder maintenance workflow will be started and follow the steps below.

SIPLACE Feeder Manager 3.3 (R18-1) / Getting Started 08/2018 Edition

5.4.1 Step 1 - Enter feeder information

The first step of the Feeder Maintenance workflow is to request for Feeder ID and the

Location this feeder is to be assigned to for maintaining.

Figure 5-24 Feeder Maintenance Workflow Step 1

Note:

Feeder IDs can also be scanned by using a wired scanner connected to the PC,

see section 5.1.1 Add New Feeder view and Feeder Console tab for details.

Feeder ID field will be pre-entered if this workflow is triggered from the Action

dropdown of a selected feeder.

Note:

For the first time this function is used, the Location ID field will be empty. Once a

maintenance location is selected, it will be used as the default maintenance location

for consequent maintenance and repair workflows, until it is changed

Press Next to continue.

5.4.2 Step 2 - Run SFTS or XFTS to check feeder

Figure 5-25 Run SFTS or XFTS to check feeder before maintain

This step provides an option for you to do feeder checking using either SFTS or XFTS

(depending on the feeder type) before proceeding to the maintenance procedure.

If you choose Yes, an SFTS verification should be done now. Feeder Manager will

automatically collect the feeder test result.

Once done, press Refresh button to have the test result displayed. Check the data and press

Next to proceed.

Or select No at the top of the form to continue without a feeder checking.
