Module Description
Electrics Assembly Kit for 1D PCB Barcode Scanner [00519890-xx] Scope of Delivery
PCB Barcode LP-Barcode 117
2.2.3 Electrics Assembly Kit for 1D PCB Barcode Scanner [00519890-xx]
2.2.4 Electrics Assembly Kit for 2D PCB Barcode Scanner [00519889-xx]
Quantity Item No. Designation
00519880-xx
contains:
PCB barcode scanner 1D SX machine
Quantities depend on the individual customer order.
2 x 03010316- xx Warning sign no. W216
00519890-xx
includes
Assembly kit PCB barcode electrics 1D SX1/2
1 x 03074066- xx Cable BC scanner DS1500 lane 1 bottom
1 x 03079352- xx Cable BC scanner DS1500 lane 1 top
1 x 03079353- xx Cable BC scanner DS1500 lane 2 bottom
1 x 03079354- xx Cable BC scanner DS1500 lane 2 top
1 x 03078130- xx USB to RS-232 converter 4x
1 x 03051322- xx USB cable type A-plug - B-plug 2m
2 x 03054625- xx Klettostar loop 20x60 mm
2 x 03054626- xx Klettostar hook 20x60 mm
03081757- xx BC-Scanner DS1500 Config. Software
This software is supplied once with each "electrics" mounting kit.
Quantity Item No. Designation
00519881-xx PCB barcode scanner 2D X/SX machine
Quantities depend on the individual customer order
00519889-xx
includes
Assembly kit PCB barcode electrics 2D SX1/2
1 x 03075944- xx Cable barcode scanner DM100 lane 1 bottom
1 x 03079389- xx Cable barcode scanner DM100 lane 1 top
1 x 03079390- xx Cable barcode scanner DM100 lane 2 bottom
1 x 03079391- xx Cable barcode scanner DM100 lane 2 top
1 x 03078149- xx Cable hub supply
1 x 03053145- xx USB hub 2.0 4-port
1 x 03051322- xx USB cable type A-plug - B-plug 2m
2 x 03054625- xx Klettostar loop 20x60 mm
2 x 03054626- xx Klettostar hook 20x60 mm
03079962- xx CD Cognex DataMan software
This software is supplied once with each "electrics" mounting kit.
Module Description
Tools and Equipment Required Electrics Assembly Kit for 2D PCB Barcode Scanner [00519889-xx]
118 PCB Barcode LP-Barcode
2.3 Tools and Equipment Required
▪ Allen key set
▪ Set of screwdrivers
▪ Diagonal cutter
2.4 Prerequisites
▪ The top code must be at least 3 mm from the side edges of the boards.
▪ The bottom code must be at least 3 mm from the side edges of the boards.
▪ Only one code can be read on the board: either top or bottom.
Minimum space between the barcode labels on lane 1 and 2
2.5 Restrictions
2.6 PCB Barcode Scanner Serial Number
The serial number of the barcode scanner can be found on the bottom of the scanner.
The minimum distance for the lens axes or the center-
point of the field of vision is approx. 88 mm. Taking into
consideration the field of vision width, a minimum space
is required between the barcode labels at lanes 1 and 2
(this does not apply to scanning of 1D codes in the X di-
rection). This is, in practice, only relevant if the PCB width
at lane 1 is near to the maximum width of the conveyor
lane.
NOTICE
Combination of various scanner types not possible
1D and 2D scanners can not be combined in one and the same machine.
NOTICE
Machines up to serial number K0261
Machines up to and including serial number K0261 can only be retrofitted with additional work.
Please contact your SIPLACE Service team in Munich for details.
Module Description
1D Barcode Scanner EU Declaration of Conformity
PCB Barcode LP-Barcode 119
2.7 EU Declaration of Conformity
2.7.1 1D Barcode Scanner
The product/device described below conforms to the regulations and standards listed in the EU Decla-
ration of Conformity provided.
Manufacturer:
Datalogic Automation S.r.l.
Via S. Vitalino 3
40012 – Lippo di Calderara
Bologna, Italy
2.7.2 2D barcode scanner
The product/device described below conforms to the regulations and standards listed in the EU Decla-
ration of Conformity provided.
Manufacturer:
Cognex Corporation
2.7.3 1D Barcode Scanner
The product/device described below conforms to the regulations and standards listed in the EU Decla-
ration of Conformity provided.
Manufacturer:
Datalogic Automation S.r.l.
Via S. Vitalino 3
40012 – Lippo di Calderara
Bologna, Italy
Product: DS1500-XXXX;
LASER SCANNER
Product: DataMan 100x
Product: DS1500-XXXX;
LASER SCANNER
