Jigs and Tools Tools ・ This section describes the grease set for CM602 maintenance. Prepare it before maintenance. Item 3-2-2 Grease Set Remark Grease gun Maker: Yamada Corporation Type: KH-35 Capacity Discharge amount/s…
Ji
g
s and Tools Tools
Dial gauge
Magnet
stand
Magnet
stand (Small)
Digital tester
Wrist band
Syringe
Key disk
MOLEX
№05800-003
AMP D3
2341 68-1
Mini MOLEX
J5800-002
AMP
189727-1
AMP
234914-1(Male)
AMP
234912-1(Female)
Square MOLEX
57031-6000
D-SUB
EJM8A-E-SMA030201-A01-00
Page 3-2-1-4
Jigs and Tools Tools
・This section describes the grease set for CM602 maintenance. Prepare it before maintenance.
Item
3-2-2 Grease Set
Remark
Grease gun
Maker: Yamada Corporation
Type: KH-35
Capacity
Discharge
amount/stroke
Maximum
pressure
Weight
400ml
(210ml cartridge)
1.00ml 25MPa 1.23kg
Item No.
852128
Filled
by hand
○
Operation
Method
Manual lever
type
210ml
cartridge
○
Greasing
Specifications
Filling Method
Main
body
Oil
case
Chain
Cap
Cartridge
grease
Lever
EJM8A-E-SMA030202-A01-00
Page 3-2-2-1
Jigs and Tools Tools
Dimensions
EJM8A-E-SMA030202-A01-00 Page 3-2-2-2
