Offset range: -5.0 to 5.0 10 11 12 Press [Offset set]. Key rsps: 0.01, 0.10, 1.00 Item Remarks 9 Select [Tray side]. Press [Pick pos teach]. Tray Shuttle Tray Offset for Tray palette pickup position Align the shuttle hea…
Precisely position the transfer and
the shuttle heads.
6
7
8
determine the key rsps.
Align the shuttle head sensor LED with the holes of the jig, using the inching keys
According to how much the shuttle head is out of place,
Remarks
Tray Shuttle Tray
Carry out the "Delivery position" teaching.
Item
Key rsps:
0.01, 0.10, 1.00
as necessary.
5
Press [Offset set].
Offset range: -3.5 to 3.5
Unrelock switch
Inching keys
EJM8A-E-SMA070102-A01-00
Page 7-1-2-3
Offset range: -5.0 to 5.0
10
11
12
Press [Offset set].
Key rsps:
0.01, 0.10, 1.00
Item Remarks
9
Select [Tray side].
Press [Pick pos teach].
Tray Shuttle Tray
Offset for Tray palette
pickup position
Align the shuttle head sensor LED with the holes of the palette extension,
using the inching keys as necessary.
According to how much the shuttle head or the transfer head is out of place,
determine the key rsps.
Unlock switch
Inching keys
EJM8A-E-SMA070102-A01-00
Page 7-1-2-4
・Jigs
Removal/Disassembly
Min.
Phillips screwdriver #2
Flat-head screwdriver #2
Allen key 3 mm
Feeler gauge
20
Part Weight
7-1-3 Positioning the Magazine Stopper
Shuttle TrayTray
This section describes the procedures for positioning the magazine stopper.
Total
Min.
FM-0545: Assembly jig
FM-0558: Palette jig
・Tools
Assembly/Adjustment
kgs.
65
Min.
30 15
Min.
Teaching
FM=055
FM=054
Dange
r
Caution
Warning
EJM8A-E-SMA070103-A01-00
Page 7-1-3-1
