5-8-2 Feeder-Cart-Unit Replacement and Adjustment
• This section describes the procedures for replacing and adjusting the feeder exchange cart unit.
20
Feeder exchange cart unit
adjustment jig
Teaching
Removal/Disassembly
Min.
Machinery Part Replacement Feeder Cart Installing Section
Part Weight
Assembly/Adjustment
60
Min.
40
Total
kgs.
・Jigs
・Tools
Phillips screwdriver #2
Allen keys 2.5mm to 6mm
Magnetic stand holding
iron plate
Magnetic stand
Dial gauge
Min.Min.
Dange
r
Warning
Caution
EJM8A-E-SMA050802-A01-00
Page 5-8-2-1
3
4
Remove the chute.
Remove the feeder cover bracket.
2
1
Remarks
Machinery Part Replacement Feeder Cart Installing Section
Switch off the power.
Remove the feeder cover.
Allen key 3 mm
Screw M4 x 10mm 3 pcs.
Thick washer 3 pcs.
Item
Phillips screwdriver #2
Screw M4 2 pcs.
Remove the left
and the right
screws. Raise
the feeder cover.
EJM8A-E-SMA050802-A01-00
Page 5-8-2-2
6
7
8
5
sensor connector.
Allen key 2.5 mm
Screw M3 4 pcs.
Disconnect the cart installation check
Remove the grease hose.
Remarks
Remove the side covers.
Item
Machinery Part Replacement Feeder Cart Installing Section
Remove the cart installation check sensor.
EJM8A-E-SMA050802-A01-00
Page 5-8-2-3
