CM602all_EJM8AESM_Service Manual.pdf - 第897页
10 Tray 12 Phillips screwdriver #2 Allen key 3mm Screw M4 2 pcs. remove the jig. Once the adjustment is complete, 11 Mount the jig on the lift. Rotate the eccentric pins so that the shaft is aligned with the jig as shown…
7
8
Raise the lift axis.
Once the adjustment is complete,
Rotate the eccentric pins so that the
Tray Shuttle Tray
6
Mount the jig on the lift.
RemarksItem
remove the jig.
Phillips screwdriver #2
Allen key 3mm
Screw M4 2 pcs.
shaft is aligned with the jig as shown below:
5
Press the jig
against the
linear rails.
The shaft should touch the
j
ig slightly.
0
FM-0545
EJM8A-E-SMA070103-A01-00
Page 7-1-3-3
10
Tray
12
Phillips screwdriver #2
Allen key 3mm
Screw M4 2 pcs.
remove the jig.
Once the adjustment is complete,
11
Mount the jig on the lift.
Rotate the eccentric pins so that the
shaft is aligned with the jig as shown below:
Item Remarks
9
Raise the lift axis by 422 st.
Shuttle Tray
Press the jig against
the linear rails.
The shaft should
touch the jig
slightly.
EJM8A-E-SMA070103-A01-00
Page 7-1-3-4
14
Item
Tray Shuttle Tray
15
Once the adjustment is complete,
Specifications:
T≦0.05㎜
Feeler gauge
Jig: FM-1188
Check the gap from the guide to
check the gap of door guide. the jig when closing the door.
16
Put the top cover back on.
Allen key 3 mm
Philips screwdriver #2
M4 x 8L 8 pcs.
M4 x 10L Truss 2 pcs.
Confirm the position of the lower stoppers.
Remarks
13
Return the lift-axis to the origin.
Door
guide
NG palette
position
Lower
position
of Lower
magazine
Magazine
shutter
EJM8A-E-SMA070103-A01-00
Page 7-1-3-5
